Samsung MAX-N75 - MAXN73 Electrical Component List

JQ1R 0505-000197 FET-SILICON;2SK373Y,N,-,-,-,400MW,TO-92
JR13 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm
HR1 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4MM
HR2 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4MM
CR1 2001-000034 R-CARBON;220OHM,5%,1/4W,AA,TP,2.4X6.4MM
FR12 2001-000034 R-CARBON;220OHM,5%,1/4W,AA,TP,2.4X6.4MM
AR11 2001-000052 R-CARBON(S);3.3KOHM,5%,1/2W,AA,TP,2.4X6.4MM
AR12 2001-000052 R-CARBON(S);3.3KOHM,5%,1/2W,AA,TP,2.4X6.4MM
RR9 2001-000055 R-CARBON;4.7Kohm,5%,1/4W,AA,TP,2.4x6.4m
LR1 2001-000109 R-CARBON(S);470OHM,5%,1/2W,AA,TP,2.4X6.4MM
AR8L 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR8R 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
JR7 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR4R 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR12L 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR10L 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR10R 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2MM
BR1 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR10A 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR12 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR2 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR21 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR25 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR27 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR28 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR29 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR3 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR30 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR31 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR34 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR36 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR4 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR5 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR9 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR3L 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR3 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR7 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
HR4 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
JR11 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
JR8L 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
HR5L 2001-000302 R-CARBON;10OHM,5%,1/8W,AA,TP,1.8X3.2MM
HR5R 2001-000302 R-CARBON;10OHM,5%,1/8W,AA,TP,1.8X3.2MM
JR20 2001-000319 R-CARBON;120KOHM,5%,1/8W,AA,TP,1.8X3.2MM
BR1R 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM
JR10L 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM
JR10R 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR4R 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR26 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RR17 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RR7 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR24 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR24 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR8L 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
HR5 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
HR9L 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
HR9R 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
BR1L 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
BR1R 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR19 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR1 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR13L 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR7 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
JW48 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RR14 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RR10 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR3R 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR5R 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
HR1R 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RR11 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RR5 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR10 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR1L 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR14 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR16 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR18 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR19 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR20 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
HR3 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
JR12 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
JR13L 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
JW99 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
LR4 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RR12 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RR15 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
JR1 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR8 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR9 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
BR3L 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
BR3R 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR11L 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR11R 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
JR14 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR2L 2001-000802 R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR1L 2001-000802 R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m
RR18 2001-000890 R-CARBON;6.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR6L 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR4 2001-001077 R-CARBON(S);150ohm,5%,1/2W,AA,TP,2.4x6.4mm
FR8 2001-001077 R-CARBON(S);150ohm,5%,1/2W,AA,TP,2.4x6.4mm
RR13 2001-001077 R-CARBON(S);150ohm,5%,1/2W,AA,TP,2.4x6.4mm
LR3 2001-001096 R-CARBON(S);2.2OHM,5%,1/2W,AA,TP,2.4X6.4MM
LR6 2001-001138 R-CARBON(S);390ohm,5%,1/2W,AA,TP,2.4x6.4mm
RR16 2001-001138 R-CARBON(S);390ohm,5%,1/2W,AA,TP,2.4x6.4mm
RR3 2001-001153 R-CARBON(S);47ohm,5%,1/2W,AA,TP,2.4x6.4mm
RR4 2001-001153 R-CARBON(S);47ohm,5%,1/2W,AA,TP,2.4x6.4mm
CR15 2001-001178 R-CARBON(S);680OHM,5%,1/2W,AA,TP,2.4X6.4MM
CR17 2001-001178 R-CARBON(S);680OHM,5%,1/2W,AA,TP,2.4X6.4MM
CR22 2001-001178 R-CARBON(S);680OHM,5%,1/2W,AA,TP,2.4X6.4MM
AR13 2003-000008 R-METAL OXIDE(S);100ohm,5%,1W,AA,TP,3.3x9mm
AR15 2003-000008 R-METAL OXIDE(S);100ohm,5%,1W,AA,TP,3.3x9mm
JSR2L 2103-000122 VR-SEMI;100Kohm,30%,1/10W,TOP
JSR2R 2103-000122 VR-SEMI;100Kohm,30%,1/10W,TOP
JSR3L 2103-000122 VR-SEMI;100Kohm,30%,1/10W,TOP
JSR3R 2103-000122 VR-SEMI;100Kohm,30%,1/10W,TOP
JSR1L 2103-000248 VR-SEMI;200KOHM,30%,1/10W,TOP
JSR1R 2103-000248 VR-SEMI;200KOHM,30%,1/10W,TOP
CVR1 2103-000341 VR-SEMI;2Kohm,30%,1/10W,TOP
CVR2 2103-000341 VR-SEMI;2Kohm,30%,1/10W,TOP
RC11 2201-000161 C-CERAMIC,DISC;10nF,+80-20%,500V,Y5V,TP,13.5x
RC12 2201-000161 C-CERAMIC,DISC;10nF,+80-20%,500V,Y5V,TP,13.5x
JC3L 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5
JC3R 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5
HC3L 2201-000381 C-CERAMIC,DISC;22NF,20%,50V,Y5V,8.0x4.0mm,5mm,TP
HC3R 2201-000381 C-CERAMIC,DISC;22NF,20%,50V,Y5V,8.0x4.0mm,5mm,TP
CC2 2201-000470 C-CERAMIC,DISC;330pF,10%,50V,SL,TP,6.5x3,5
AC5L 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12.5x4.0mm,5mm,TP
AC5R 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12.5x4.0mm,5mm,TP
AC7L 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12.5x4.0mm,5mm,TP
AC7R 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12.5x4.0mm,5mm,TP
- 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,-
JC2L 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,-
JC1LA 2202-000820 C-CERAMIC,MLC-AXIAL;5.6NF,20%,16V,Y5R,TP,3.5X19,-
JC1RA 2202-000820 C-CERAMIC,MLC-AXIAL;5.6NF,20%,16V,Y5R,TP,3.5X19,-
AC6L 2301-000375 C-FILM,PEF;100nF,5%,50V,TP,11x12.5x6.5,7m
AC6R 2301-000375 C-FILM,PEF;100nF,5%,50V,TP,11x12.5x6.5,7m
FC6 2301-000375 C-FILM,PEF;100nF,5%,50V,TP,11x12.5x6.5,7m
LC4 2301-000404 C-FILM,PEF;2.2NF,10%,50V,TP,5.5X7X3.2MM,5
LC1 2301-000407 C-FILM,PEF;2.7NF,10%,50V,TP,5.5X7X3MM,5MM
AC2 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5
JC6L 2301-000419 C-FILM,PEF;27nF,10%,50V,TP,7.5x10.5x4mm,5
JC6R 2301-000419 C-FILM,PEF;27nF,10%,50V,TP,7.5x10.5x4mm,5
FC10 2301-000449 C-FILM,PEF;47NF,10%,50V,TP,8X11X4.5MM,5MM
LC5 2301-000456 C-FILM,PEF;56NF,10%,50V,TP,8X12X4.5MM,5MM
CC1 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
RC15 2401-000357 C-AL;100UF,20%,50V,GP,-,8X11.5,3.5M
AC12 2401-000385 C-AL;10uF,20%,100V,GP,TP,6.3x11,5
AC9 2401-000385 C-AL;10uF,20%,100V,GP,TP,6.3x11,5
BC1L 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
BC1R 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
BC2 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
BC3L 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
BC3R 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
JC1L 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
JC1R 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
JC4 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
JC6 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
AC10 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
AC11 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
FC12L 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
FC12R 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
FC14L 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
FC14R 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
FC17L 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
FC17R 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
RC8 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
FC3 2401-000778 C-AL;220uF,20%,10V,GP,-,6.3x11,2.5m
FC8 2401-000778 C-AL;220uF,20%,10V,GP,-,6.3x11,2.5m
JC15 2401-000778 C-AL;220uF,20%,10V,GP,-,6.3x11,2.5m
JC5 2401-000778 C-AL;220uF,20%,10V,GP,-,6.3x11,2.5m
HC1 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M
HC2 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M
RC16 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M
FC2 2401-000970 C-AL;22uF,20%,50V,WT,TP,5x11,5
AC1 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
BC2L 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
BC2R 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
FC12 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
FC5 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
JC3 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
AC13 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
AC4L 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
AC4R 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
DC1 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
FC16L 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
FC16R 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
LC2 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
RC10 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
Samsung Electronics 3-9
