Samsung MAX-N75 - Parts List of Total Exploded View(MAX-N73)

Samsung Electronics 2-5
2-2-3 Parts List of Total Exploded view(MAX-N73)
No. Code No. Description ; Specification Q’ty Remarks
1 AH64-00615C CABINET-FRONT MIPS L/GRAY(G6236) 1 NONE MIC
AH64-00615D CABINET-FRONT MIPS L/GRAY(G6236) 1 USE MIC 1
2 AH64-70003H BADGE-SAMSUNG SAMSUNG,SILVER 30mm 1
3 AH64-00621B WINDOW-CD PMMA 850-71129 1
4 AH64-00620B DOOR-CD ABS L/GRAY(G6236) 1
5 AH64-00622F WINDOW-DOOR.CD PMMA 850-71129 1
6 AH61-00366B CAP-FUNCTION ABS D/GRAY(G3174) 1
7 AH64-00623B WINDOW-VFD PMMA 850-41802 1 NONE RDS
AH64-00623C WINDOW-VFD PMMA 850-41802 1 USE RDS
8 AH64-00639B KNOB-VOLUME ABS L/GRAY(G6236) 1
9 AH64-00624B WINDOW-DOOR,A PMMA 850-83239 1
USE DOLBY MARK
AH64-00624C WINDOW-DOOR,A PMMA 850-83239 1 NONE DOLBY MARK
10 AH64-00625B WINDOW-DOOR,B PMMA 850-83239 1
11 AH64-00618B DOOR-CASS.A ABS L/GRAY(G6236) 1
12 AH64-00619B DOOR-CASS.B ABS L/GRAY(G6236) 1
13 AH61-00365A HOLDER-DOOR,A ABS L/GRAY (G6236) 1
14 AH61-00378A HOLDER-DOOR,B ABS L/GRAY (G6236) 1
15 AH61-62004C SPRING-EJECT,A SUS 304 PI 1.0 1
16 AH61-62005C SPRING-EJECT,B SUS 304 PI 1.0 1
17 AH61-00376A BRKT-MIC SECC 1.0T 1
18 AH64-00632B KNOB-POWER ABS L/GRAY (G6236) 1
19 AH67-00056A LENS-POWER PMMA MILKY 1
20 AH64-00634A KNOB-TIMER ABS D/GRAY(G3174) 1
21 AH64-00631B KNOB-DISC ABS D/GRAY (G3174) 1
22 AH67-00055A LENS-DISC PMMA CLR 1
23 AH64-00630B KNOB-OPEN ABS L/GRAY (G6236) 1
24 AH64-00635B KNOB-FUNCTION ABS D/GRAY(G3174) 1
25 AH67-00057A LENS-FUNCTION PMMA CLR 1
26 AH64-00636A KNOB-TURBO ABS D/GRAY(G3174) 1
27 AH67-00058B LENS-TURBO PMMA CLR 1
28 AH64-00637B KNOB-EQ,1 ABS L/GRAY(G6236) 1
29 AH64-00638B KNOB-EQ,2 ABS L/GRAY(G6236) 1
30 AH95-50001A LATCH ASSY POM BLACK 2
31 AH61-80030A DAMPER ASSY POM BLACK 2
32 AH64-00627B KNOB-JOG ABS L/GRAY (G6236) 1
33 AH67-00059B LENS-JOG PMMA CLR 1
34 AH64-00626B DECO-JOG ABS D/GRAY (G3174) 1
35 AH61-00369B CAP-MOV,TOP ABS L/GRAY (G6236) 1
36 AH67-00061A LENS-ENTER PMMA CLR 1
37 AH64-00628B KNOB-ENTER ABS L/GRAY (G6236) 1
38 AH67-00060A LENS-MOVING PMMA MILKY 1
39 AH61-00370A CAP-MOV,BOTTOM PC/ABS GRAY(1PB-0401) 1
40 AH61-00372A HOLDER-FEED NYLON 6/6 BLK 1
41 AH61-00374A BRKT-FEED SUS 301 1/4H 1
42 AH61-00371A HOLDER-MOVING PC/ABS GRAY(1PB-0401) 1
43 AH61-00367B CAP-UPPER ABS GRAY(1PB-0401) 1 USE DOLBY NR
AH61-00367C CAP-UPPER ABS GRAY(1PB-0401) 1 NONOE DOLBY NR
44 AH67-00062A LENS-RECORD PMMA MILKY 3
45 AH64-00629B KNOB-DECK ABS L/GRAY (G6236) 1
46 AH61-00368A CAP-BOTTOM ABS D/GRAY(G3174) 1
47 AH61-00399B SHAFT-GUIDE SUS 303 1
48 AH66-00114A PULLEY-MOTOR POM BLK 1
49 AH66-00108A BELT CR, MAX-N75 1
50 AH66-00110A PULLEY-SHAFT POM BLK 1
51 AH61-00375A BRKT-STOPPER SUS 301 1/4H 1
52 AH61-00399A SHAFT-FEED SUS 303 1
53 AH64-00373A HOLDER-VFD ABS WHT 1
54 AH64-00616A CABINET-TOP PCM 0.625T SILVER 1
55 AH64-30416C CABINET-BOTTOM SECC 1.0T 1
56 AH61-20540A HOLDER-TUNER PC/ABS BLACK 1
57 AH64-00617B CABINET-REAR SECC 0.8T 1 1 VOL
AH64-00617C CABINET-REAR SECC 0.8T 1 2 VOL
AH64-00617D CABINET-REAR SECC 0.8T 1 1 VOL + SW
AH64-00617E CABINET-REAR SECC 0.8T 1 2 VOL + SW
AH64-00617F CABINET-REAR SECC 0.8T 1 1 VOL + DIGITAL OUT
58 AH64-00640B KNOB-MIC,VOL ABS L/GRAY(G6236) 1 OPTION
59 AH64-00633B KNOB-ECHO ABS L/GRAY(G6236) 1 OPTION
