JW149 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
FR18L 2007-000030 R-CHIP;560OHM,5%,1/10W,DA,TP,2012
FR18R 2007-000030 R-CHIP;560OHM,5%,1/10W,DA,TP,2012
JR4 2007-000032 R-CHIP;390KOHM,5%,1/10W,DA,TP,2012
JW113 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW1A 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW2A 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW3A 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
AR8L 2007-000221 R-CHIP;1.2KOHM,5%,1/10W,DA,TP,2012
AR8R 2007-000221 R-CHIP;1.2KOHM,5%,1/10W,DA,TP,2012
JR8 2007-000221 R-CHIP;1.2KOHM,5%,1/10W,DA,TP,2012
FR4L 2007-000241 R-CHIP;1.5KOHM,5%,1/10W,DA,TP,2012
HR3L 2007-000241 R-CHIP;1.5KOHM,5%,1/10W,DA,TP,2012
HR3R 2007-000241 R-CHIP;1.5KOHM,5%,1/10W,DA,TP,2012
FR12R 2007-000267 R-CHIP;1.8KOHM,5%,1/10W,DA,TP,2012
DR1 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
DR6 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
FR9 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
AR5 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
CR10 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
CR11 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
CR35 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
CR7 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
DR3L 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
DR3R 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
FR13 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
FR14 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
FR1R 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
FR2 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
FR5 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
JR15 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
JR20 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
JR5 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
JR5L 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
JR5R 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
JR8R 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
JR9 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
LR2 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
BR6L 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
BR6R 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
JR11L 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
AR4L 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
FR18 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
FR1A 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
JR15A 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
BR2 2007-000477 R-CHIP;1MOHM,5%,1/10W,DA,TP,2012
AR4 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
FR20 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
FR8R 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
FR9L 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
FR9R 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
HR2L 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
HR2R 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
HR4L 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
HR4R 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
JR4L 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
JR4R 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
FR10 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
FR13R 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
FR2L 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
FR2R 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
FR6 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
JR3 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
JR7L 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
JR7R 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
AR3L 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
AR5L 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
BR5L 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
BR5R 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
HR1L 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
AR1 2007-000774 R-CHIP;33KOHM,5%,1/10W,DA,TP,2012
AR6 2007-000774 R-CHIP;33KOHM,5%,1/10W,DA,TP,2012
FR15 2007-000774 R-CHIP;33KOHM,5%,1/10W,DA,TP,2012
BR2L 2007-000822 R-CHIP;390OHM,5%,1/10W,DA,TP,2012
BR2R 2007-000822 R-CHIP;390OHM,5%,1/10W,DA,TP,2012
DR2 2007-000830 R-CHIP;39KOHM,5%,1/10W,DA,TP,2012
AR1R 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
BR1L 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
CR37 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
JR13R 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
JR6 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
RR6 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
AR2L 2007-000941 R-CHIP;47KOHM,5%,1/10W,DA,TP,2012
AR2R 2007-000941 R-CHIP;47KOHM,5%,1/10W,DA,TP,2012
AR7 2007-000941 R-CHIP;47KOHM,5%,1/10W,DA,TP,2012
DR1L 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
DR1R 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
DR2R 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
JR1R 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
JR7 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
AR6L 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
AR6R 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
AR7L 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
AR7R 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
DR9L 2007-001071 R-CHIP;6.8KOHM,5%,1/10W,DA,TP,2012
DR9R 2007-001071 R-CHIP;6.8KOHM,5%,1/10W,DA,TP,2012
FR7L 2007-001071 R-CHIP;6.8KOHM,5%,1/10W,DA,TP,2012
FR7R 2007-001071 R-CHIP;6.8KOHM,5%,1/10W,DA,TP,2012
CR39 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
CR6 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
CR8 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
FR6R 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
JR10 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
JR12L 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
JR12R 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
FC1A 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
FC5L 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
FC5R 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
FC7 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
FC9 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
EMC1 2203-000239 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,2012
EMC2 2203-000239 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,2012
FC6L 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
FC6R 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
JC2 2203-000361 C-CERAMIC,CHIP;0.15nF,5%,50V,NP0,TP,2012
FC5 2203-000374 C-CERAMIC,CHIP;15nF,10%,50V,X7R,TP,2012
FC11L 2203-000533 C-CERAMIC,CHIP;2.7nF,10%,50V,X7R,TP,2012,-
FC11R 2203-000533 C-CERAMIC,CHIP;2.7nF,10%,50V,X7R,TP,2012,-
FC8L 2203-000533 C-CERAMIC,CHIP;2.7nF,10%,50V,X7R,TP,2012,-
FC8R 2203-000533 C-CERAMIC,CHIP;2.7nF,10%,50V,X7R,TP,2012,-
JC11L 2203-000595 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,2012
JC11R 2203-000595 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,2012
FC7L 2203-000671 C-CERAMIC,CHIP;27nF,10%,50V,X7R,TP,2012,-
FC7R 2203-000671 C-CERAMIC,CHIP;27nF,10%,50V,X7R,TP,2012,-
FC3L 2203-000761 C-CERAMIC,CHIP;330nF,10%,16V,X7R,TP,2012,-
FC3R 2203-000761 C-CERAMIC,CHIP;330nF,10%,16V,X7R,TP,2012,-
AC1L 2203-000787 C-CERAMIC,CHIP;0.33nF,5%,50V,NP0,TP,2012
AC1R 2203-000787 C-CERAMIC,CHIP;0.33nF,5%,50V,NP0,TP,2012
CC3 2203-000787 C-CERAMIC,CHIP;0.33nF,5%,50V,NP0,TP,2012
CC4 2203-000787 C-CERAMIC,CHIP;0.33nF,5%,50V,NP0,TP,2012
CC5 2203-000787 C-CERAMIC,CHIP;0.33nF,5%,50V,NP0,TP,2012
FC4L 2203-000802 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,2012
FC4R 2203-000802 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,2012
JC10L 2203-000892 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,2012
JC10R 2203-000892 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,2012
AC11L 2203-000953 C-CERAMIC,CHIP;0.47nF,5%,50V,NP0,TP,2012
AC11R 2203-000953 C-CERAMIC,CHIP;0.47nF,5%,50V,NP0,TP,2012
FC1 2203-000953 C-CERAMIC,CHIP;0.47nF,5%,50V,NP0,TP,2012
JC10L 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
JC10R 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
JC22 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
JC27 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
JC4L 2203-001058 C-CERAMIC,CHIP;0.56nF,5%,50V,NP0,TP,2012
JC4R 2203-001058 C-CERAMIC,CHIP;0.56nF,5%,50V,NP0,TP,2012
JC5L 2203-001058 C-CERAMIC,CHIP;0.56nF,5%,50V,NP0,TP,2012
JC5R 2203-001058 C-CERAMIC,CHIP;0.56nF,5%,50V,NP0,TP,2012
AC3L 2203-001090 C-CERAMIC,CHIP;0.005nF,0.25pF,50V,NP0,TP,2012
AC3R 2203-001090 C-CERAMIC,CHIP;0.005nF,0.25pF,50V,NP0,TP,2012
FC9L 2203-001214 C-CERAMIC,CHIP;8.2nF,10%,50V,X7R,TP,2012,-
FC9R 2203-001214 C-CERAMIC,CHIP;8.2nF,10%,50V,X7R,TP,2012,-
FC10L 2203-001230 C-CERAMIC,CHIP;0.82nF,5%,50V,NP0,TP,2012
FC10R 2203-001230 C-CERAMIC,CHIP;0.82nF,5%,50V,NP0,TP,2012
FC4 2203-001537 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012
JC2R 2203-001537 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012
FC1L 2203-001611 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,2012
FC1R 2203-001611 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,2012
AH92-00565A ASSY PCB;MAX-N75,FRONT S.N.A.
UIR1 0601-000564 LED-IR;SIDE-VIEW,1.5MM,100MW,5V,940MM
ULD17 0601-001238 LED;ROUND,RED,3.1mm,697nm
ULD21 0601-001432 LED;ROUND,BLUE,3mm,455nm
ULD22 0601-001432 LED;ROUND,BLUE,3mm,455nm
UPQ1 0603-000116 PHOTO-TR;NPN,30V,6V,40MA,100MW,-
UPQ2 0603-000116 PHOTO-TR;NPN,30V,6V,40MA,100MW,-
UPQ3 0603-000116 PHOTO-TR;NPN,30V,6V,40MA,100MW,-
OJACK1 0603-001051 OPTIC TRANSMITTER;5V,6Mb/s,5m,-15dBm,660nm,20mA
UIC5 1003-001162 IC-MOTOR DRIVER;KA3082,SIP,10PIN,25MIL,DOUBLE,
UIC3 1203-000276 IC-POSI.FIXED REG.;7805,TO-220,3P,-,PLASTIC,4.8/5
UX2 2801-001394 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAY,12.5pF,
UX1 2802-000181 RESONATOR-CERAMIC;6MHZ,0.3%,BK,9.0X4.0X7.5MM
OFT1 2901-001139 FILTER-EMI ON BOARD;50V,.5A,-,390PF,7X2.5X5MM,TP,RADIAL
ELE1 3406-001047 SWITCH-ROTARY;5V DC,0.5mA,-,12mm
JOG 3406-001054 SWITCH-ROTARY;5V DC,0.5mA,-,7.5mm
UCW3 3708-000122 CONNECTOR-FPC/FC/PIC;11P,1.25mm,ANGLE,SN
UCW12 3708-000331 CONNECTOR-FPC/FC/PIC;9P,1.25mm,ANGLE,SN
UCW10 3708-000448 CONNECTOR-FPC/FC/PIC;6P,1.25MM,STRAIGHT,
UCW7 3708-000448 CONNECTOR-FPC/FC/PIC;6P,1.25MM,STRAIGHT,
UCW5 3708-000450 CONNECTOR-FPC/FC/PIC;11P,1.25MM,STRAIGHT,
UCW2 3708-000454 CONNECTOR-FPC/FC/PIC;22P,1.25MM,STRAIGHT,
UCW4 3708-000492 CONNECTOR-FPC/FC/PIC;9P,1.25MM,-,SN
UCW15 3708-001027 CONNECTOR-FPC/FC/PIC;6P,1.25MM,ANGLE,SN
UCW16 3708-001027 CONNECTOR-FPC/FC/PIC;6P,1.25MM,ANGLE,SN
UCW1 3708-001488 CONNECTOR-FPC/FC/PIC;30P,1.25mm,ANGLE,SN
UCW11 3711-000826 CONNECTOR-HEADER;BOX,2P,1R,2mm,ANGLE,SN
OCW1 3711-000907 CONNECTOR-HEADER;BOX,3P,1R,2mm,STRAIGHT,SN
UCW6 3711-000907 CONNECTOR-HEADER;BOX,3P,1R,2mm,STRAIGHT,SN
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
Samsung Electronics 3-17
