Samsung MAX-VB630 - Parts List of Total Exploded View

Samsung Electronics 2-3
* Parts List of Total Exploded view
No. Description Code No. Q’ty Specification REMARK
1 DOOR-CD AH64-01704B 1 ABS L/GRAY
2 WINDOW-DOORCD AH64-01749F 1 PMMA BROWN VB630
3 WINDOW-VFD AH64-01705C 1 PMMA BROWN
4 SHEET-VFD AH63-00395A 1 PC 0.4T
5 KNOB-MIC AH64- 01715B 1 ABS L/GRAY
6 CAP-MIC.D AH64-00964B 1 ABS L/GRAY “MIC, NO RDS”
7 KNOB-CONTRL AH64-01713B 1 ABS CLEAR HOT/STAMPING
8 COVER-CONTROL AH61-00965A 1 ABS BLK
9 KNOB-STOP AH64-01718B 1 PC BLUE
10 CAP-CONTROL AH61-00980B 1 AL 0.8T
11 KNOB-JOG AH64-01710B 1 ABS L/GRAY
12 WINDOW-DOOR.A AH64-01706A 1 PMMA BROWN
13 WINDOW-DOOR.B AH64-01707A 1 PMMA BROWN
14 DOOR-CASS.A AH64-01701B 1 ABS L/GRAYFULL LOGIC
AH64-01701C 1 ABS L/GRAYAUTO REVERSE
15 DOOR-CASS.B AH64-01702B 1 ABS L/GRAYAUTO REVERSE
16 HOLDER-DOOR.A AH61-01011A 1 ABS L/GRAY
17 HOLDER-DOOR.A AH61-01012A 1 ABS L/GRAY
18 KNOB-SOUND AH64-01716B 1 ABS L/GRAY
19 KNOB-VOLUME AH64-01711B 1 ABS L/GRAY
20 KNOB-SUBWOOFER AH64-01717B 1 ABS L/GRAY
21 LENS-SOUND AH64-00157A 1 PMMA BLUE
22 LENS-VOLUME AH67-00156A 1 PMMA BLUE
23 LENS-SUBWOOFER AH67-00160A 1 PMMA BLUE
24 BADGE-BRAND AH64-70003K 1 ABS BLK HOT/STAMPING
25 CABINET-FRONT AH64-01700B 1 ABS L/GRAYNO RDS
26 KNOB-OPEN AH64-01709B 1 ABS L/GRAY
27 KNOB-DEMO AH64-01714B 1 ABS L/GRAY
28 LENS-STANDBY AH67-00159A 1 PMMA MILKY
29 KNOB-POWER AH64-01708B 1 ABS L/GRAY
30 KNOB-ECHO AH64-01719B 1 ABS L/GRAY
31 LENS-FUNCTION AH67-00154C 1 PMMA BLUE
32 HOLDER-FUNCTION AH61-00967A 1 ABS WHITE
33 LENS-P.SOUND AH67-00155A 1 PMMA CLEAR
34 HOLDER-P.SOUND AH61-00970A 1 ABS BLK
35 KNOB-ENTER AH64-01712B 1 ABS L/GRAY
36 LATCH ASSY AH95-50001A 2 POM
37 DAMPER AH61-80030A 2 POM
38 SPRING .A AH61-00522A 1 STS
39 SPRING .B AH61-00523A 1 STS
40 HEAT-SINK IC AH62-00044A 1 AL
41 SUPPORT-RIVET AH61-00414A 3 POM
42 SUPPORT-PCB AH61-00021A 1 ABS BLK
43 COVER-PCBAH63-00278A 1 EVA
No. Description Code No. Q’ty Specification REMARK
40 HEAT-SINK IC AH62-00044A 1 AL
41 SUPPORT-RIVET AH61-00414A 3 POM
42 SUPPORT-PCB AH61-00021A 1 ABS BLK
43 COVER-PCB AH63-00278A 1 EVA
44 BRACKET-PCB AH61-00685A 1 SECC0.8T
45 BRACKET-H/SINK.L AH61-00973A 1 SECC1.0T
46 BRACKET-H/SINK.R AH61-00977A 1 SECC1.0T
47 HEAT-SINK.M AH62-00063A 1 AL WB650
AH62-00063D 1 AL WB630
48 CABINET-BOTTOM AH64-03416E 1 SECC 1.0T
49 CABINET-REAR AH64-01703G 1 SECC 0.8T 1 VOL
AH64-01703H 1 SECC 0.8T 2 VOL
AH64-01703J 1 SECC 0.8T 1VOL+SW
AH64-01703K 1 SECC 0.8T 2VOL+SW
50 COVER-REAR AH61-00969A 1 ABS L/GRAY
51 CABINET-TOP AH64-00616A 1 SECC 0.8T
