5-22Samsung Electronics
Exploded Views and Parts List
■
Parts List
Q'TY
No.
Code No. Description Specification SA/SNA
1 DB90-01364B ASS'Y CABINET FRONT ASS'Y 1 SA
1-1 DB63-00831A GUARD FAN PP,SC-90073R 1 SA
2 DB90-01908A ASS'Y BASE OUT ASS'Y 1 SNA
3 DB67-00438A FAN PROPELLER PP 1 SA
4 DB31-00268B MOTOR FAN SGCC-M 1 SA
5 DB90-00966B ASS'Y BRACKET MOTOR ASS'Y 1 SA
6 DB94-00694A ASS'Y PARTITION ASS'Y 1 SNA
7 DB96-04466A ASS'Y CONDENSER ASS'Y 1 SA
8 DB61-02364A GUIDE SCREEN P.E.H 100% 1 SC
9 DB90-01907A ASS'Y CABINET SIDE ASS'Y 1 SA
10 DB90-40176B ASS'Y COVER CONTROL ASS'Y 1 SA
11 DB90-10616R ASS'Y CABINET UPPER ASS'Y 1 SA
12 DB63-00343A GUARD CONDENSER SECC-P 1 SA
13 G4B135LU1EH ROTARY COMPRESSOR BLDC PERMANENT MAGNETIC MOTOR 1 SA
13-1 DB73-00070A GROMMET-ISOLATOR NR 3 SNA
14 DB96-04469A ASS'Y TUBE SUCTION ASS'Y 1 SA
15 DB99-00607A ASS'Y VALVE 4-WAY ASS'Y 1 SA
16 DB99-00608A ASS'Y VALVE ASS'Y 1 SA
16-1 DB96-04450A ASS'Y TUBE EEV A ASS'Y 1 SA
16-2 DB96-04451A ASS'Y TUBE EEV B ASS'Y 1 SA
17 DB93-03142A ASS'Y CONTROL OUT ASS'Y 1 SA
17-1 DB93-03143A ASS'Y PCB MAIN ASS'Y 1 SA
18 DB81-00534A REACTOR 5MH±5%,40.0±5V 1 SA
19 DB32-00081C THERMISTOR CONDENSER 103AT,204CTB 1 SA
20 DB32-00083G THERMISTOR 103AT,204CTB 1 SA
