Samsung MH052FXEA2 - Page 104

Exploded Views and Parts List
5-24Samsung Electronics
■
Parts List
Q'TY
SA/SNA
No. Code No. Description Specification
1 DB90-01006B ASS'Y CABINET FRONT 1 1 1 SA
1-1 DB63-00831A GUARD FAN 1 1 1 SA
2 DB90-01049E ASS'Y BASE OUT 1 1 1 SNA
3 DB67-00438A FAN PROPELLER 1 1 1 SA
4 DB31-00268A MOTOR FAN 1 1 1 SA
5 DB90-01114B ASS'Y BASE MOTOR 1 1 1 SNA
6 DB94-00308B ASS'Y PARTITION 1 1 1 SNA
7 DB96-03808B ASS'Y COND 1 1 1 SNA
8 DB64-00765A SCREEN GUARD FIN 1 1 1 SA
9 DB90-01008B ASS'Y CABINET SIDE 1 1 1 SA
10 DB90-01742A ASS'Y COVER CONTROL 1 1 1 SA
11 DB90-01007B ASS'Y COVER TOP 1 1 1 SA
12 DB63-01058A GUARD COND 1 1 1 SA
13 G5T360FU1EK ROTARY COMPRESSOR 1 1 1 SA
13-1 DB73-00082A GROMMET-ISOLATOR 3 3 3 SNA
14 DB96-03803B ASS'Y TUBE SUCTION 1 1 1 SA
15 DB96-03788A ASS'Y 4-WAY VALVE 1 1 1 SA
16 DB99-00557A ASS'Y VALVE 1 1 1 SA
16-1 DB96-03789A ASS'Y TUBE EEV A 1 1 1 SA
16-2 DB96-03790A ASS'Y TUBE EEV B 1 1 1 SA
16-3 DB96-03791A ASS'Y TUBE EEV C 1 1 1 SA
16-4 DB96-03792A ASS'Y TUBE EEV D 1 1 1 SA
17 DB93-02892A ASS'Y CONTROL OUT 1 - 1 SA
DB93-02892B ASS'Y CONTROL OUT - 1 - SA
17-1 DB93-02893A ASS'Y PCB MAIN 1 1 1 SA
18 DB81-00534A REACTOR 1 1 1 SA
19 DB32-00081B THERMISTOR COND 1 1 1 SA
20 DB32-00083D
THERMISTOR WIRE OUT/DISCHARGE
111SA
21 DB62-02929A TUBE RECEIVER 1 1 1 SNA
MH30VP2X
MH30VW2X
MH068FXEA4 MH080FXEA4
ASS'Y
PP,SC-90073R
ASS'Y
PP(LUPOL LW4302)
SGCC-M
ASS'Y
ASS'Y
ASS'Y
P.E.H 100%
ASS'Y
ASS'Y
ASS'Y
SECC-P
BLDC INVERTER
NR
ASS'Y
ASS'Y
ASS'Y
ASS'Y
ASS'Y
ASS'Y
ASS'Y
ASS'Y
ASS'Y
ASS'Y
5mH±20%,34.0±5%
103AT,204CTB
103AT,204CTB
R410A,t=1.52mm
