Electrical Parts List
6-8Samsung Electronics
■ MAIN PCB : DB93-03542A(MH023/026/035FWEA,MH✳✳VW2-✳✳)(cont.)
IC06 0506-000175 IC-BUS TRANSCEIVER 2003,NPN,7,1W,SOP-16,ST,1000 1 SNA
IC07 0506-000175 IC-CMOS LOGIC 2003,NPN,7,1W,SOP-16,ST,1000 1 SNA
IC08 1003-001462 IC-EEPROM TD62783AFW,SOL,18P,-,8,-500mA 1 SNA
IC18 1006-001325 THERMISTOR-NTC 1487,SO,8P,4.9x3.8 mm,SINGLE,S 1 SNA
IC19 1006-001325 PHOTO-COUPLER 1487,SO,8P,4.9x3.8 mm,SINGLE,S 1 SNA
IC20 0801-000393 PHOTO-COUPLER 74HC86,OR GATE,SOP,14P,150MIL 1 SNA
IC51 1103-001175 PHOTO-COUPLER 93LC56,128x16,SOP,8P,5x4mm,2.5 1 SNA
NTC1 1404-001274 TR-SMALL SIGNAL 22ohm,1.4A,3100K,9.5mW/C,-,7.0 1 SNA
PC01 0604-000117 TR-SMALL SIGNAL TR,130-260%,200mW,DIP-4,ST 1 SNA
PC02 0604-001003 TR-SMALL SIGNAL TR,50-150%,200mW,DIP-4,ST 1 SNA
PC03 0604-001148 TR-SMALL SIGNAL TR,50-600%,200mW,SMD-4,TP 1 SNA
Q201 0501-000534 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SOT-23,TP,1 1 SNA
Q311 0501-000534 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SOT-23,TP,1 1 SNA
Q501 0501-000534 R-CHIP 2SC2412K,NPN,200mW,SOT-23,TP,1 1 SNA
Q601 0501-000534 R-CHIP 2SC2412K,NPN,200mW,SOT-23,TP,1 1 SNA
Q602 0501-002296 R-COMPOSITION MMST2907A,PNP,200mW,SMT3,TP,10 1 SNA
Q603 0501-000534 R-COMPOSITION 2SC2412K,NPN,200mW,SOT-23,TP,1 1 SNA
R101 2007-000290 R-CHIP 100ohm,5%,1/8W,TP,2012 1 SNA
R102 2007-000493 R-CHIP 2.2Kohm,5%,1/8W,TP,2012 1 SNA
R103 2002-001104 R-CHIP 12Mohm,5%,1/2W,AA,TP,3.4x9mm 1 SNA
R104 2002-001104 R-CHIP 12Mohm,5%,1/2W,AA,TP,3.4x9mm 1 SNA
R105 2007-000931 R-CHIP 470ohm,5%,1/8W,TP,2012 1 SNA
R201 2007-000944 R-CHIP 47Kohm,5%,1/4W,TP,3216 1 SNA
R202 2007-000944 R-CHIP 47Kohm,5%,1/4W,TP,3216 1 SNA
R203 2007-000944 R-CHIP 47Kohm,5%,1/4W,TP,3216 1 SNA
R204 2007-000944 R-CHIP 47Kohm,5%,1/4W,TP,3216 1 SNA
R205 2007-000944 R-CHIP 47Kohm,5%,1/4W,TP,3216 1 SNA
R206 2007-000944 R-CHIP 47Kohm,5%,1/4W,TP,3216 1 SNA
R207 2007-000944 R-CHIP 47Kohm,5%,1/4W,TP,3216 1 SNA
R208 2007-000944 R-CHIP 47Kohm,5%,1/4W,TP,3216 1 SNA
R209 2007-000300 R-CHIP 10Kohm,5%,1/8W,TP,2012 1 SNA
R210 2007-000468 R-CHIP 1Kohm,5%,1/8W,TP,2012 1 SNA
R211 2007-000468 R-CHIP 1Kohm,5%,1/8W,TP,2012 1 SNA
R212 2007-000468 R-CHIP 1Kohm,5%,1/8W,TP,2012 1 SNA
R302 2007-000300 R-CHIP 10Kohm,5%,1/8W,TP,2012 1 SNA
R303 2007-000300 R-CHIP 10Kohm,5%,1/8W,TP,2012 1 SNA
R304 2007-000300 R-CHIP 10Kohm,5%,1/8W,TP,2012 1 SNA
R305 2007-000300 R-CHIP 10Kohm,5%,1/8W,TP,2012 1 SNA
R306 2007-000300 R-CHIP 10Kohm,5%,1/8W,TP,2012 1 SNA
R307 2007-000300 R-CHIP 10Kohm,5%,1/8W,TP,2012 1 SNA
Location No. Code No. Description Q'TY SA/SNA RemarkSpecification
