Electrical Parts List
6-10Samsung Electronics
■ MAIN PCB : DB93-03542A(MH023/026/035FWEA,MH✳✳VW2-✳✳)(cont.)
SS71 3502-000115 RESONATOR-CERAMIC 12Vdc,-,2A,1mS,1mS 1 SNA
ST11 DB26-00015A C-FILM,LEAD-PPF -,JT1916-09,-,310V,FERRITE,-,E 1 SNA
VA71 1405-000154 C-FILM,LEAD-PPF 560V,2500A,17.5x7.5mm,TP 1 SNA
X501 2802-001179 DIODE-ZENER 4MHz,0.5%,BK,8x3x5.5mm 1 SNA
XC71 2301-001439 DIODE-ZENER 220nF,10%,275V,BK,18x10x15.8mm 1 SNA
XC72 2301-001220 C-FILM,LEAD-PPF 100nF,10%,275V,BK,18x6x12,15 1 SNA
ZD11 0403-000252 DIODE-ZENER BZX84C3V6,3.4-3.8V,350mW,SOT-2 1 SNA
ZD12 0403-001285 DIODE-ZENER BZX84-C11,10.4-11.6V,350mW,SOT 1 SNA
CD312 0406-001204 DIODE-TVS SMBJ5.0CA,6.4/-/7.07V,600W,SMB 1 SNA
CD334 0406-001204 DIODE-TVS SMBJ5.0CA,6.4/-/7.07V,600W,SMB 1 SNA
F701_1 3601-000263 FUSE-CARTRIDGE 250V,3.15A,TIME-LAG,GLASS,5x20 1 SNA
Location No. Code No. Description Q'TY SA/SNA RemarkSpecification
24296A(1)_1 11/11/05 5:04 PM Page 4-67
