Electrical Parts List
6-12Samsung Electronics
■ MAIN PCB : DB93-03542B(MH052FWEA)(cont.)
C805 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C806 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C807 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C808 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C811 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C812 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C813 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C814 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C815 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C816 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C817 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C911 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,TP,2012 1 SNA
C912 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,TP,2012 1 SNA
C913 2203-001562 DIODE-TVS 10nF,+80-20%,50V,Y5V,TP,2012 1 SNA
C917 2203-001562 DIODE-TVS 10nF,+80-20%,50V,Y5V,TP,2012 1 SNA
C918 2203-000192 DIODE-TVS 100nF,+80-20%,50V,Y5V,2012 1 SNA
CD11 0406-001086 CONNECTOR-HEADER ST02D-200,185/200/215V,200W,DO 1 SNA
CN10 3711-005716 CONNECTOR-HEADER BOX,10P,1R,2mm,STRAIGHT,SN,BLK 1 SNA
CN31 3711-000177 CONNECTOR-HEADER 1WALL,2P,1R,3.96mm,STRAIGHT,SN 1 SNA
CN32 3711-000178 CONNECTOR-HEADER 1WALL,2P,1R,3.96mm,STRAIGHT,SN 1 SNA
CN33 3711-000176 CONNECTOR-HEADER 1WALL,2P,1R,3.96mm,STRAIGHT,SN 1 SNA
CN41 3711-004379 CONNECTOR-HEADER BOX,4P,1R,2mm,STRAIGHT,SN 1 SNA
CN42 3711-003942 CONNECTOR-HEADER BOX,2P,1R,2mm,STRAIGHT,SN 1 SNA
CN44 3711-000879 CONNECTOR-HEADER BOX,3P,1R,2.5mm,STRAIGHT,SN 1 SNA
CN60 3711-004484 CONNECTOR-HEADER BOX,5P,1R,2mm,STRAIGHT,SN 1 SNA
CN61 3711-002001 CONNECTOR-HEADER BOX,20P,2R,2mm,STRAIGHT,SN,BLK 1 SNA
CN71 3711-003404 C-FILM,LEAD-PPF 1WALL,2P,1R,7.92mm,STRAIGHT,SN 1 SNA
CN73 3711-000262 DIODE-RECTIFIER 1WALL,3P,1R,7.92mm,STRAIGHT,SN 1 SNA
CN82 3711-005206 FUSE-CLIP BOX,3P,1R,2mm,STRAIGHT,SN,BLU 1 SNA
CN85 3711-005205 FUSE-RADIAL LEAD BOX,3P,1R,2mm,STRAIGHT,SN,RED 1 SNA
CR71 2301-001371 COIL CHOKE 2000nF,+10-5%,450V,BK,38x19x29 1 SNA
D101 0402-001194 IC-PWM CONTROLLER SHG2D,200V,2A,-,TP 1 SNA
F701 3602-000147 IC-POSI.FIXED REG 250V,7.5A,30mohm 1 SNA
F702 3601-001209 IC-RESET 250V,1A,TIME-LAG,-,8.5x8mm 1 SNA
FT71 DB27-00011A IC MICOM LS404190K,AS-S660,19mH,+50,-30 1 SNA
IC01 1203-002545 TR-ARRAY 266,DIP,8P,300MIL,PLASTIC,-0.3 1 SNA
IC02 1203-000429 TR-ARRAY 78L05A,TO-92,3P,-,PLASTIC,4.6 1 SNA
IC03 1203-003334 TR-ARRAY S-801,SOT-23,5P,2.9x1.6mm,PLASTIC 1 SNA
IC04 DB09-00346B IC-SOURCE DRIVER MB90F823,-,80 P,5 V,24 MHz,STM 1 SNA
IC05 0506-000175 IC-BUS TRANSCEIVER 2003,NPN,7,1W,SOP-16,ST,1000 1 SNA
Location No. Code No. Description Q'TY SA/SNA RemarkSpecification
24296A(1)_1 11/11/05 5:04 PM Page 4-69
