Samsung ML-3471ND/XAX User Manual

3.11 Drive Ass'y 3-15
3.12 Duplex Drive Ass'y
3-16
3.13 Shield SMPS Ass'y
3-17
3.14 Connection PCB
3-18
3.15 Fuser Drive Ass'y
3-19
3.16 Fan
3-20
3.17 Pick Up Roller Ass'y
3-21
3.18 Duplex Guide Housing (With Feed Roller)
3-22
3.19 HVPS Housing
3-23
3.20 Cover Mid Front
3-24
3.21 MPF Housing
3-24
3.22 Feed Roller Parts
3-25
3.23 Pick Up Gear Ass'y & Solenoids
3-27
3.24 Exit Roller
3-27
3.25 LSU
3-28
3.26 TERMINAL
3-28
3.27 Transfer Roller Parts
3-29
4. Alignment & Troubleshooting
4.1 Alignment and Adjustments 4-1
4.1.1 Sample Pattern
4-1
4.1.2 Control Panel
4-2
4.1.3 Consumables and Replacement Parts
4-7
4.1.4 LED Status Error Message
4-7
4.1.5 Abnormal Image Printing and Defective Roller
4-10
4.1.6 How to use DCU
4-11
4.1.7 Paper Jam
4-16
4.1.8 Download & Reset F/W
4-22
4.2 Troubleshooting
4-23
4.2.1 Procedure of Checking the Symptoms
4-23
4.2.2 The cause and solution of Bad image
4-24
Continued
