5. Exploded Views and Parts List

(S.N.A : SERVICE NOT AVAILABLE)

Level No. Code No. Description Specication Q’ty SA/

SNA

Remark

1-1 M041 0402-001554 HVDIODE-RECTIFIER HV03-12T01,12000V,0.4A 1 SA -

1-1 M039 2501-001016 C-OIL 950nF,2.1KV,BK,35x54x80,20mm 1 SA -

1-1 M036 4713-001046 LAMP-INCANDESCENT 240V,104mA,25W,ORG,-,- 1 SA -

1-1 M038 DE26-00099A TRANS H.V SHV-EURO1-1,230V,50HZ,2330V,3. 1 SA -

1-1 M049 DE31-10154A MOTOR SYNCHRONOUS M2HJ49ZR02,ST-16,50/60 1 SA -

1-1 Z778 DE47-20008A THERMOSTAT PW2N-52JC,100/60,250V/7.5A,H, 1 SA -

1-1 M040 DE61-00139A BRACKET-HVC NC2000,SECC,T0.8,-,-,-,0.6/0 1 SA -

1-1 M047 DE61-40066A FOOT -,PP,-,BLK,-,-,- 1 SA -

1-1 M001 DE64-00350K PANEL-OUTER MGB 22 C/STEEL,T0.5GE-WHT 1 SA -

1-1 M099 DE66-90113A LEVER-DOOR PP(TB53-GH41),T2.5,-,-,12g,NT 1 SA -

1-1 M034 DE67-00140A COUPLER PPS,(ESS840),3G,BRN,NEW 1 SA -

1-1 M022 DE71-00148A COVER-BLOWER PP,T1.5NTR MW850WA NC2000 1 SA -

1-1 M051 DE71-00151A COVER MGT PP,T2,W54,L129,GE-WHTMW850WA 1 SA -

1-1 M037 DE71-60457C COVER-AIR 3RD-0.7(BTM),PP(FB53 G30),-,-, 1 SA -

1-1 T001 DE74-00027A TRAY-COOKING GLASS,T5,-,NC2000 1 SA -

1-1 M048 DE80-00023A BASE PLATE SGCC T0.6 MW850WA NC2000 1 SA -

1-1 M042 DE91-70061J ASSY-H.V.FUSE THV060T-0650-H,5KV0.65A,WL 1 SA -

1-1 M017 DE96-00010C ASSY NOISE FILTER SN-3WED(12),250V12A,EU 1 SA -

1-2 M019 3601-001019 FUSE-CARTRIDGE 250V,12A,SLOW-BLOW,CERAMI 1 SA -

1-1 M020 DE96-00031A ASSY-MOTOR FAN SMF-3RDEA,230V50HZ,2400RP 1 SA -

1-2 M023 DE31-10184A MOTOR-FAN SMF-3RDEA,230V50Hz,2400rpm,3rd 1 SA -

1-2 H018 DE31-90057A BLADE-FAN PP,T1.5,-,3RD-W,-,-,- 1 SA -

1-1 B018 DE96-00115C ASSY BODY LATCH CE2611N,NC2000(BUTTON) 1 SA -

1-2 B002 3405-001032 SWITCH-MICRO 125/250VAC,16A,200GF,SPDT 1 SA -

1-2 B001 3405-001034 SWITCH-MICRO 125/250VAC,16A,200GF,SPST-N 2 SA PRI,SEC

1-2 B009 DE66-00088A LEVER-SWITCH NC2000(0.6/0.8/1.2),PP,-,-, 1 SA -

1-2 B006 DE72-00138B BODY-LATCH NC2000(0.6/0.8/1.2),PP(FH44N) 1 SA -

1-1 M015 DE96-00385D ASSY POWER CORD CEE,EU,250V/8A,1500MM,30 1 SA -

1-1 W002 DE96-00407A ASSY-WIRE HARNESS A MW87W,CMO 1 SA -

1-1 T017 DE97-00193B ASSY-GUIDE ROLLER NC2000 0.6,T2*P1198(14 1 SA -

1-1 M035 OM75S(31)ESGN ASSY-MGT 1 SA -

5-2 Main Parts List
