37
5. Exploded Views and Parts List
5-5 Standard Parts List
(S.N.A : SERVICE NOT AVAILABLE)
Level Code No. Description Specication Q’ty SA/
SNA
Remark
1-1 6002-001250 SCREW-TAPPING TH,+,2,M4,L8,Tin-Ni,SWRC18 1 SNA O/PANEL
1-1 6006-001170 SCREW-ASSY TAPP WS,TH,+,M4,L10,ZPC(YEL) 3 SA PCB EARTH,P/C EARTH,NOISE FILTER EARTH
1-1 6006-001176 SCREW-ASSY TAPT WT,PH,+,M4,L8,ZPC(YEL) 1 SNA BKT HVC & DIODE
1-1 DE60-10051A SCREW-TAP PH -,-,MSWR,-,PH,M4,-,L6,-,- 1 SA DRIVE MOTOR
1-1 DE60-10080A SCREW-WASHER -,-,-,-,M5,L12,-,2S,-,- 2 SA HVT,MGT
1-1 DE60-10082I SCREW-A -,-,-,-,2S-4X10,FEFZY,-,-,-,- 7 SA C/BLOWER,B/PLATE,B/LATCH,AIR/
COVER,PANEL
1-1 DE60-30016A NUT-FLANGE M4,MSWR10,-,-,-,-,-,-,- 1 SA F-MOTOR
1-2 6002-000630 SCREW-TAPPING PH,+,2S,M3,L8,ZPC(YEL),SWR 2 SA HOLDER PCB,PCB
