3. Disassembly and Reassembly
Parts Explaination Photo Explaination
Magnetron,
Motor Assembly
and Lamp
4
. Remove screws securing the
magnetron to the wave guide.
5. Take out the magnetron very
carefully.
6. Remove two screws from the
back panel.
7. Take out the fan motor.
3-1 Disassembly of Magnetron, Motor Assembly and Lamp
