Samsung MX-J730 - Pin Connection

5.PCBDiagram
5.2.1.PinConnection
1)FCN1
ConnecttoVFD
PinNo.Signal
1DGND
2VP
3-VFD
4+VFD
5DGND
6VFD_CE
7VFD_CLK
8VFD_DO
9KEY3
10RE_IN
11ST_5V
12ST_5V
13DGND'
2)FCN2
ConnecttoVFD
PinNo.Signal
1DGND
2VP
3-VFD
4+VFD
5DGND
6VFD_CE
7VFD_CLK
8VFD_DO
9KEY3
10RE_IN
11ST_5V
12ST_5V
13DGND'
3)CN1
ConnecttoMain
PinNo.Signal
1-VP
2VFD-
3VFD+
4DGND
5VFD_CE
6VFD_CLK
7VFD_DO
8JOG-
9JOG+
10DGND
11KEY_AD2
12KEY_AD1
13DGND
14REMOTE
15ST_5.1V
16USB1_5V
17USB1_DN
18USB1_DN
19USB1_DP
20USB1_DP
21USB2_5V
22GND
23USB2_DN
24USB2_DN
25USB2_DP
26USB2_DP
27DGND
