Ⅲ. EXPLODED VIEW AND PART LIST
3-1
AD62-00084A CHAMBER BODY 1 O BLACK
AD62-00078A CHAMBER BODY 1 O SILVER
3-2 6107-001454 BATTERY_PUSH_SPRING 1 O
3-3 AD61-03222A MAIN_FRAME 1 O
3-4 AD63-02626A HDMI_SHIELD_FOAM 1 O
3-5 AD61-03223A BATTERY_HOLDER_PLATE 1 O
3-6 AD63-02629A BATT_SHIELD_FOAM 3 O
3-7 AD66-00497A BATTERY_LOCK_LEVER 1 O
3-8 6107-001429 BATTERY LOCK LEVER SPRING 1 O
3-9 AD61-03575A BATTEY_LOCK_LEVER_HINGE 1 O
3-10 6003-001633 SCREW B 5 X
3-11 AD63-03076A CUSHION-MOTOR 1 X
3-12 AD63-03003A CUSHION-BATTERY COVER 1 X
3-13 AD63-02839A TOUCH_BUTTON_TAPE 1 X
3-14 AD63-02351A TOP_SHIELD_FOAM 2 X
3-15 AD63-03028A SHEET-TOUCH BUTTON 1 X
3-16 AD63-02813A MAIN_FRAME_SHEET 1 X
▶
▶
PARTS LIST
Fig.No Parts No. Parts Name Q’ty Available Parts Remarks
