Ⅴ. ADJUSTMENT
A. Purpose
Matching between the OIS Mecha and the LIS algorithm (hall gain, hall offset, actuator gain, etc) i.e. treat it
as NG if the measurement value of the moving distance for the OIS Mecha falls outside the standard.
Adjust and test by giving and receiving commands and required values through the I2C communication
between the camera and the OIS.
B. Procedures
1. Save the corresponding adjustment file into the SD card.
2. Install the SD card containing the program file and turn the camera on.
3. The adjustment is conducted automatically.
The OIS module moves up, down, left and right two to three times.
4. When the adjustment is complete, the camera will automatically be turned off.
3.
OIS Centering ADJ
