41
- This Document can not be used without Samsung's authorization -
Ⅲ. EXPLODED VIEW AND PART LIST
7-1
AD64-01782A FRONT_DECO_RING 1 O BLACK
AD64-01793A FRONT_DECO_RING 1 O SILVER
7-2 AD64-01842A FRONT_PANEL-UW4 1 X
7-3 AD63-01528A BARRIER_C-UW4 2 X
7-4 6107-001473 BARRIER_CLOSE_SPRING-UW4 2 X
7-5 AD63-01527A BARRIER_B-UW4 1 X
7-6 AD63-01526A BARRIER_A-UW4 1 X
7-7 AD61-03263A BARRIER_BASE-UW4 1 X
7-8 AD66-00483A BARRIER_LEVER-UW4 1 X
7-9 6107-001472 BARRIER_OPEN_SPRING-UW4 1 X
7-10 6002-001418 BARRIER SCREW_A-SZA8518 2 X
7-11 AD66-00537A BARRIER LEVER PIN-SZA8518 1 X
7-12
AD64-01781A CAM_DECO_RING 1 x BLACK
AD64-01784A CAM_DECO_RING 1 X SILVER
7-13 AD63-01928A CAM_SHIELD-UW4 1 X
7-14
AD67-00733A CAM_BARREL 1 X BLACK
AD67-00746A CAM_BARREL 1 X SILVER
7-15 AD67-00732A GUIDE_BARREL-UW4 1 X
7-16 AD67-00734A OUTER_BARREL-UW4 1 X
7-17 AD61-03264A SHUTTER_FPCB_GUIDE-UW4 1 X
7-18 AD63-01924A 1ST_BARREL_SHIELD_A-UW4 1 X
7-19
AD67-00735A ZOOM_RING 1 X BLACK
AD67-00747A ZOOM_RING 1 X SILVER
7-20 AD67-00604A G1_LENS-NV2_104W 1 X
7-21 AD67-00610A G2_LENS-NV2_104W 1 X
7-22 AD63-01929A 1ST_BARREL_SHIELD_B-UW4 1 X
▶
▶
PARTS LIST
Fig.No Parts No. Parts Name Q’ty Available Parts Remarks
To Next Page
