Connection



Ensure you connect each of the adapters to the correct RS232C IN or OUT port on the product.

 Connection 1

RS232C

IN OUT

RS232C

IN OUT

RS232C

IN OUT

RS232C

IN OUT

 Connection 2

HDBT (LAN IN) HDBT (LAN IN)

 Connection 3

RS232C

OUT

HDBT (LAN IN) RS232C

IN OUT

RS232C

IN OUT

RS232C

IN OUT
