43
Connection using a cross LAN cable
The appearance may differ depending on the product.
Multiple products can be connected using the RS232C IN / OUT port on the product.
Monitor 1
Monitor 2
Computer
RS232C OUT
RS232C OUT
RS232C IN
RS232C IN
RJ45 (LAN OUT)
