Samsung OMN Series - Page 15

Stand bracket specification
4 ~ Φ10 mm
69.5 mm
20 mm
(Space for cable
insertion)
20 mm
(Space for cable
insertion)
OM46N-D: 548.5 mm
OM55N-D: 740 mm
50 mm
55 mm
58 mm
A-A’
Product Bracket
B side
(outward)
A side
(inner)
A side
(inner)
A side
(inner)
B side
(outward)
A-A’ one side
Recommended structure thickness:
3.0 t ~ 4.0 t
Set
Φ10 mm
External Φ 20 mm
(Screw head size ↑)
Cable space
(10 mm or more)
English - 15
OM46N-D / OM55N-D
