3.DisassemblyandReassembly
DescriptionDescriptionPhotoScrew
3.Liftupandremovetherear-cover.
4.Removethescrewsofmainboard.
CAUTION
Disconnectallconnectorspriortoremoving
boards.
6001–002606
M3*L10
5.RemovethescrewsofSMPS.
RemovetheSMPS.
6001–002606
M3*L10
6003–001439
M3*L10
6.RemovethescrewofFunction.
RemovetheFunction.
6001–002606
M3*L10
Copyright©1995-2013SAMSUNG.Allrightsreserved.3-2
