5.WiringDiagram
5.WiringDiagram
5.1.OverallWiring
■43"FV
CN5007
CN800S
CN5008
CN5009
CN5010
CN5011
CN5012
CN5000
CN2501
CN2004_LO
CN2002_LO
CN4000
CN2609
CN201_CO
CN4007
CN2008_LO
CN4009
CN1202_3D
XY –
DRIVE
S MP S
X- Buffe r
Logic +
Ma in Boa rd
E- BUFFER
CN
1
FUNC TIO N
E- BUFFER
S pe ake r (L) S pe ake r (R)
CN5002
CN902
NOTE
Thecodenumberofcable(Lead-connector)canbechanged,see“ExplodedViewsandPartsList”.
UsePowerCable22PinFunctionCable8Pin
CodeBN39-01768A(90mm)BN39-01591A(150mm)
