Samsung QE75T - Connection; Connection 1

38
Connection
"
Ensure you connect each of the adapters to the correct RS232C IN or OUT port on the
product.
"
Connecting parts may differ depending on the model.
 Connection 1
RS232C IN RS232C OUT RS232C IN RS232C OUT RS232C IN RS232C OUT RS232C IN RS232C OUT
Monitor 1 Monitor 2 Monitor 3 Monitor 4
PC
 Connection 2
RJ45(LAN IN)RJ45(LAN IN) RJ45 RJ45(LAN IN)
5 4 3 2 1
Monitor 2Monitor 1
PC
Monitor 3
 Connection 3
RS232C OUT RS232C IN RS232C OUT RS232C IN RS232C OUT RS232C IN RS232C OUTRJ45(LAN IN)RJ45
Monitor 1 Monitor 2 Monitor 3 Monitor 4
PC
 Connection 4
"
This option is only available for models that have LAN IN and LAN OUT ports.
LAN OUTLAN IN LAN OUTLAN IN LAN OUTLAN IN LAN OUTLAN INRJ45
Monitor 1 Monitor 2 Monitor 3 Monitor 4
PC
