18
1. Unplug the power cord.
5. Electric box assembly
Make sure the power cord is
unplugged before replacing any
electric components.
Mechanical Disassembly
2. Remove the screws of the compartment cover.
Slide it up and take out from the refrigerator.
3. Mechine compartment assembly
Machine Compartment
＆＆
Electric Box
Warning
4. Disassemble the electric box cover after
removing the screws with a Phillips screwdriver.
To Next Page
