29
DISASSEMBLY AND REASSEMBLY
3-11) Vegetable & Fruit Drawers Shelf
3-10) Foldable Glass Shelf
Foldable Glass
Shelf
Part Name How To Do Descriptive Picture
Remove 2 screws of the Fold
Glass Shelf
Vegetable & Fruit
Drawers Shelf
Part Name How To Do Descriptive Picture
1. Remove the vegetable & fruit
drawer by pulling the roller part
and lifting it up.
2. Remove the vegetable & fruit
drawers shelf by pulling it out.
(Refer to the picture)
