39
DISASSEMBLY AND REASSEMBLY
3-22) Pull Out Drawer
Pull Out Drawer
Part Name How To Do Descriptive Picture
1. Slide the drawer out as much as
possible.
2. Insert a flat screw driver(-) into
the gap and then push it up to
diassemble.
3. Remove the pull out drawer by
lifting the bottom part of drawer
bin and pulling it out.
To Next Page
