Samsung RF267AASH - 3-3) Door Switch in Refrigerator; 3-4) Door Gasket; 3-5) Door Handle

25
3-3) Door Switch In Refrigerator
DISASSEMBLY AND REASSEMBLY
3-4) Door Gasket
3-5) Door Handle
Door Switch
In Refrigerator
Part Name How To Do Descriptive Picture
1. Remove the magnet switch with
using a flat-blade(-) screwdriver.
(Refer to the picture)
Door Gasket
In Refrigerator
Part Name How To Do Descriptive Picture
1. Remove the door-gasket by
pulling it out of the retaining
channel.
Door Handle
Refrigerator
Door Handle
Freezer
Part Name How To Do Descriptive Picture
1. Remove the door handle of
refrigerator by lifting it up and
pulling it out.
(Refer to the picture)
1. Remove the door handle of
freezer by pushing it to the right
and pulling it out.
(Refer to the picture)
