38
DISASSEMBLY AND REASSEMBLY
3-21) Freezer Door
Freezer
Door
Part Name How To Do Descriptive Picture
1. Pull the drawer open to full
extension.
2. Remove the tilting Pocket( ) by
pulling the both brackets( )
upward at the same time.
3. Take out the lower basket( ) by
lifting the basket up from rail
system.
4. Remove a fixing pin( ) and
remove a shaft( ) by pushing it
to the right side with your hand.
5. Separate the rail from the rail
cover by pushing the hooks (
)
in on both sides of the rail. After
pusing the hooks in, remove the
drawer by pulling towards you
with both hands.
①
②
③
⑤
④
⑥
