44
DISASSEMBLY AND REASSEMBLY
Relay
PTC & O/L
Water Valve
Part Name How To Do Descriptive Picture
1. Disengage the housing
connector.
2. Remove the relay PTC with a
flat-blade screwdriver.
(Refer to the picture)
1. Unscrew the water valve fixed
by the screw.
2. Remove the the hook part of the
hose by pushing it down.
3. Remove 2 water hose parts
while pushing the upper part of
.
(Refer to the picture)
4. Disengage 2 housing connector
parts.
5. Remove the hose connected by
the nut with a wrench(8mm).
To Next Page
