Samsung S24C770T User Manual

2
Table of contents
Before Using the Product
Copyright 4
Securing the Installation Space 5
Precautions for storage 5
Safety Precautions 5
Symbols 5
Cleaning 6
Electricity and Safety 6
Installation 7
Operation 9
Correct posture to use the product 12
Tilting the product 12
Preparations
Checking the Contents 13
Removing the Packaging 13
Checking the Components 14
Parts 15
Front Buttons 15
Reverse Side 16
Adjusting the Product Tilt 17
Anti-theft Lock 18
Using MagicTune Touch
About MagicTune Touch 19
Requirements 19
Installing/Uninstalling MagicTune Touch
(Windows) 20
Installation 20
Uninstallation 20
Installing MagicTune Touch (Mac) 20
Installation 20
Using a touchscreen monitor
Touchscreen monitor 21
Requirements 21
Read below before using the product 21
Connecting the touchscreen monitor 22
Connecting to a PC 22
Connecting to a laptop or tablet PC 22
Configuring the touchscreen monitor
settings 23
Accessing the calibration menu 23
Calibration 25
Configuring the touchscreen monitor settings
from a Mac 27
Installing Touch Base 27
Controlling the screen 28
Basic touch functions 28
Notes 29
Connecting and Using a Source
Device
Before Connecting 30
Pre-connection Checkpoints 30
Connection Using an HDMI Cable 31
Connecting to a PC 31
Connecting to a Video Device 31
Connection Using an HDMI-DVI Cable 32
Connecting to a PC 32
Connecting to a Video Device 32
Connecting to an Audio System 33
Connecting the Power 33
Changing the Resolution 34
Changing the Resolution on Windows 7 34
Changing the Resolution on Windows 8 34
OSD menu
Exiting from the menu 35
Adjusting the brightness 35
Changing the screen size 36
In PC mode 36

Samsung S24C770T Specifications

General

Full HD	Yes
Depth (imperial)	1.96 \
Width (imperial)	22.10 \
Height (imperial)	13.07 \
Dimensions (WxDxH)	561.3 x 49.78 x 332 mm
Accessories included	Quick Setup Guide, Cleaning Cloth, Install CD (Manual), HDMI Cable, Power Cable, USB Cable
Dimensions (W x D x H) with stand	561.3 x 191.8 x 373.9 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	24 \
Display brightness	250 cd/m²
Display technology	LED
Contrast ratio (typical)	3000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	60.96 cm
Dynamic contrast ratio marketing name	Mega Contrast
Product color	Black
NVIDIA G-SYNC	No
Compatible operating systems	Windows 8
Cables included	HDMI, USB
AC input voltage	110 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	32 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	191.8 mm
Width (with stand)	561.3 mm
Height (with stand)	373.9 mm
Weight (with stand)	12100 g
Depth (without stand)	49.78 mm
Height (without stand)	332 mm
Weight (without stand)	11220 g
