Alignment and adjustment
Samsung Electronics 5-5
SC-L100 SC-L150
MODE OSD DATA1 DATA2 DATA1 DATA2 NAME OF ADJUSTMENT
98 B-OUT 5C 5C 5C 5C B OUTDOOR CONTROL VALUE
B8 CFAPS 20 20 20 20 NOISE SLICE START AGC
B9 APNSC FE FE FE FE NOISE SLICE MAXIMUM VALUE
BB CFAOR O3 O3 O3 O3 CHROMA SUPRESS MAXIMUM VALUE
BC BLKST 30 30 30 30 EY BLACK START AGC
BD BLKMX O4 O4 O4 O4 EY BLACK MAXIMUM VALUE
00 OO OO OO OO NOT USED
01 40 40 40 40 HALL GAIN
02 80 80 80 80 HALL REFERENCE
03 70 70 70 70 IRIS LEVEL CONTROL-HIGH BYTE
04 OO OO OO OO IRIS LEVEL CONTROL-L
O5 40 40 40 40 P.CLK ADJUSTMENT
06 OO OO OO OO P.CLK PWM CONTROL-L
O7 OO OO OO OO A/D REFERENCE CONTROL(SETUP)
O8 0F 0F 0F 0F SOFT CLIP CONTROL
O9 18 18 18 18 AGC CONTROL
OA 66 66 66 66 H/V BLACK NOIS THRESHOLD/GAIN
OB 58 58 58 58 HORIZONTAL APPERTURE GAIN
OC F8 F8 F8 F8 VERTICAL APPERTURE GAIN
0D 0B 0B 0B 0B APERTURE SLICE CONTROL
OE A8 A8 A8 A8 Y HI-REF. VALUE FOR C SUPRESS
OF 10 10 10 10 EDGE REF. VALUE FOR C SUPRESS
10 05 05 05 05 Y SIGNAL GAMMA COEFF. 1
11 0A 0A 0A 0A Y SIGNAL GAMMA COEFF. 2
12 1C 1C 1C 1C Y SIGNAL GAMMA COEFF. 3
13 30 30 30 30 Y SIGNAL GAMMA COEFF. 4
14 4D 4D 4D 4D Y SIGNAL GAMMA COEFF. 5
15 76 76 76 76 Y SIGNAL GAMMA COEFF. 6
16 B8 B8 B8 B8 Y SIGNAL GAMMA COEFF. 7
17 DA DA DA DA Y SIGNAL GAMMA COEFF. 8
18 OO OO OO OO Y LPF SELECTION
19 11 11 11 11 Cr/Cb/Y LPF SELECTION
1A 42 42 42 42 C MATRIX COEF. OF Cr SIGNAL
1B 66 66 66 66 C MATRIX COEF. OF Cb SIGNAL
1C 3D 3D 3D 3D COLOR W/B COEFF. OF Cr SIGNAL
1D 90 90 90 90 COLOR W/B COEFF. OF Cb SIGNAL
1E 24 24 24 24 C W/B COEF. OF G SIGNAL
1F 05 05 05 05 C DARK SLICE COEF. OF Cr SIG.
20 01 01 01 01 C DARK SLICE COEF. OF Cb SIG.
21 FB FB FB FB C DARK SLICE COEF. OF G SIG.
22 05 05 05 05 C SIGNAL GAMMA BENDING POINT 1
23 0D 0D 0D 0D C SIGNAL GAMMA BENDING POINT 2
24 1A 1A 1A 1A C SIGNAL GAMMA BENDING POINT 3
25 38 38 38 38 C SIGNAL GAMMA BENDING POINT 4
26 58 58 58 58 C SIGNAL GAMMA BENDING POINT 5
27 88 88 88 88 C SIGNAL GAMMA BENDING POINT 6
28 B8 B8 B8 B8 C SIGNAL GAMMA BENDING POINT 7
29 DA DA DA DA C SIGNAL GAMMA BENDING POINT 8
2A 59 59 59 59 Cr(R-G) SIGNAL POSITIVE GAIN
2B 59 59 59 59 Cr(R-G) SIGNAL NEGATIVE GAIN
2C F2 F2 F2 F2 Cr(B-G) SIGNAL POSITIVE GAIN
2D F2 F2 F2 F2 Cr(B-G) SIGNAL NEGATIVE GAIN
2E D9 D9 D9 D9 Cb(R-G) SIGNAL POSITIVE GAIN
2F D9 D9 D9 D9 Cb(R-G) SIGNAL NEGATIVE GAIN
30 72 72 72 72 Cb(B-G) SIGNAL POSITIVE GAIN
31 72 72 72 72 Cb(B-G) SIGNAL NEGATIVE GAIN
32 38 38 38 38 INDOOR R-Y POSITIVE GAIN
33 38 38 38 38 INDOOR R-Y NEGATIVE GAIN
34 09 09 09 09 INDOOR R-Y POSITIVE GAIN
35 O8 O8 O8 O8 INDOOR R-Y NEGATIVE GAIN
36 1E 1E 1E 1E INDOOR B-Y POSITIVE GAIN
