Alignment and adjustment
5-6 Samsung Electronics
SC-L100 SC-L150
MODE OSD DATA1 DATA2 DATA1 DATA2 NAME OF ADJUSTMENT
37 18 18 18 18 INDOOR B-Y NEGATIVE GAIN
38 18 18 18 18 INDOOR B-Y POSITIVE GAIN
39 01 01 01 01 INDOOR B-Y NEGATIVE GAIN
3A C8 C8 C8 C8 NEGA MODE W/B B CONTROL
3B 28 28 28 28 SPOT MODE AE TARGET
3C 35 35 35 35 R DETECT WINDOW H START POINT
3D 50 50 50 50 R DETECT WINDOW H STOP POINT
3E 3A 3A 3A 3A R DETECT WINDOW V START POINT
3F 4B 4B 4B 4B R DETECT WINDOW V STOP POINT
40 OO OO OO OO DSP ODM COMMEND
41 30 30 30 30 CLIP COUNTER THRESHOULD
42 7B 7B 7B 7B COLOR ADJUST START VALUE
43 85 85 85 85 R TARGET UP/DOWN OF D ZOOM
44 OO OO OO OO B TARGET UP/DOWN OF D ZOOM
45 FF FF FF FF SHUTTER OF D ZOOM
46 00 00 00 00 CCD DEFECT COMPENSATION FACTOR
47 F0 F0 F0 F0 ODM AE CLIP THRESHOULD VALUE
48 FF FF FF FF ODM Y UPPER VALUE OF AE MODE
49 OO OO OO OO ODM Y LOWER VALUE OF AE MODE
4A 3F 3F 3F 3F ODM Y UPPER VALUE OF AWB MODE
4B OO OO OO OO ODM Y LOWER VALUE OF AWB MODE
4C FF FF FF FF R-Y THRESHOULD VALUE OF AWB MODE
4D FF FF FF FF B-Y THRESHOULD VALUE OF AWB MODE
4E 3F 3F 3F 3F (R-Y)+(B-Y) THRESHOULD VALUE
4F 20 20 20 20 WHITE DETECTION THRESHOLD VALUE
50 OO OO OO OO DIGITAL CLAMP OPTICAL BLACK POINT
51 O2 O2 O2 O2 Y DELAY CONTROL SELECTION
52 A0 A0 A0 A0 Y SIGNAL GAIN
53 80 80 80 80 CHROMA GAIN CONTROL
54 83 83 83 83 Y SET-UP LEVEL CONTROL
55 AE AE AE AE WHITE CLIP CONTROL
56 2C 2C 2C 2C LUMINANCE BLANK LEVEL
57 EE EE EE EE B-Y SIGNAL BURST LEVEL CONTROL
58 00 00 00 00 R-Y SIGNAL BURST LEVEL CONTROL
59 87 87 87 87 BURST FLAG DELAY SELECTION
5A OO OO OO OO FSC/2FSC CONTROL
5B OO OO OO OO DELAY CONTROL SELECTION
5C 3F 3F 3F 3F DELAY CONTROL SELECTION
5D 00 00 00 00 SCK CONTROL
5E 01 01 01 01 D/ZOOM MODE SELECTION
5F 02 O2 O2 O2 TG MODE SELECTION
60 OO OO OO OO INVERSE NUMBER OF V ZOOM RATIO
61 09 09 09 09 CCD V START POINT(INTEGER LINE)
62 OO OO OO OO CCD V START POINT(SUB PIXEL)
63 83 83 83 83 SHUTTER MODE
64 FF FF FF FF HIGH SHUTTER SPEED CONTROL
65 00 00 00 00 H1/H2/RG DELAY CONTROL
66 D9 D9 D9 D9 SHP/SHD DELAY CONTROL
67 OO OO OO OO SPO/FECKDELAY CONTROL
68 OO OO OO OO RG/SHP PULSE WIDTH ADJUSTMENT
69 80 80 80 80 D ZOOM MODE SELECTION
6A OO OO OO OO HORIZONTAL D ZOOM STEP
6B OO OO OO OO VERTICAL D ZOOM STEP
6C OO OO OO OO HORIZENTAL START READ ADDRESS -H
6D O1 O1 O1 O1 HORIZENTAL START READ ADDRESS -L
6E OO OO OO OO HORIZONTAL D ZOOM START SUB PIXEL
6F OO OO OO OO V D ZOOM START SUB PIXEL ODD FIELD
70 OO OO OO OO V D ZOOM START SUB PIXEL EVEN FIELD
71 36 36 36 36 OUTDOOR R-Y POSITIVE GAIN
72 2C 2C 2C 2C OUTDOOR R-Y NEGATIVE GAIN
To Next Page
