Samsung SCL100 - Page 45

Note : On table you see the ÒXX XXÓ for DATA 1/DATA 2
ÒXX XXÓ means arbitrary value.
<Example of the TV screen>
CD HALLA XX XX
Data in
memory
Data to be
adjusted
Alignment and adjustment
5-24 Samsung Electronics
VP-L100 VP-L150
MODE OSD DATA1 DATA2 DATA1 DATA2 NAME OF ADJUSTMENT
DB O8 O8 O8 O8 HALL CHECK THRESHOULD
DC 82 82 82 82 COLOR ADJUST TARGET VALUE
DD 89 89 89 89 HALL ADJUST GAIN TARGET
DE 4D 4D 4D 4D HALL ADJUST CENTER
DF 00 00 00 00 NOT USED
E0 AA AA AA AA BK NOISE TH/GAIN OF EIS
E1 5F 5F 5F 5F H APPERTURE GAIN OF EIS
E2 FF FF FF FF #0C OF EIS ON
E3 0B 0B 0B 0B #OD OF EIS ON
E4 A8 A8 A8 A8 #OE OF EIS ON
E5 10 10 10 10 #OF OF EIS ON
E6 OO OO OO OO #18 OF EIS ON
E7 80 80 80 80 B OUTDOOR CONTROL UP/DOWN OF W/B ADJUST
E8 69 69 69 69 V GAIN-1(A/D GAIN)
E9 80 80 80 80 R TARGET OF W/B AUTO ADJUSTMENT
EA EB EB EB EB V GAIN-3(CENTERING GAIN)
EB 06 06 06 06 V STOP NOISE THRESHOULD
EC 8C 8C 8C 8C H GAIN-1(A/D GAIN)
ED 7F 7F 7F 7F B TARGET OF W/B AUTO ADJUSTMENT
EE EB EB EB EB H GAIN-3(CENTERING GAIN)
EF 09 09 09 09 H STOP NOISE THRESHOULD
F0 OO OO OO OO D-ZOOM STEP
F1 O1 O1 O1 O1 NOT USED
