Samsung SCL100 - Page 82

RP27 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP28 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP29 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP30 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP31 2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,1608
RP32 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
RP33 2007-000450 R-CHIP;180ohm,5%,1/16W,DA,TP,1608
RP34 2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,1608
RP35 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
RP36 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
RP37 2007-000828 R-CHIP;39Kohm,1%,1/16W,DA,TP,1608
RP38 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP39 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP40 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP41 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP42 2007-000512 R-CHIP;2.4Kohm,5%,1/16W,DA,TP,1608
RP43 2007-000104 R-CHIP;150Kohm,5%,1/16W,DA,TP,1608
RP44 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
RP45 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608
RP46 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608
RP47 2007-000104 R-CHIP;150Kohm,5%,1/16W,DA,TP,1608
RP48 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
RP49 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP50 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
RP51 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RP53 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
RP54 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP55 2007-000637 R-CHIP;270Kohm,5%,1/16W,DA,TP,1608
RP56 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
RP57 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP58 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP59 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP65 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP66 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608
RP67 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP68 2007-000863 R-CHIP:4.3ohm,5%,1/10W,DA,TP,2012
RP69 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608
RP70 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608
RP71 2007-000863 R-CHIP:4.3ohm,5%,1/10W,DA,TP,2012
RP72 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP73 2007-000863 R-CHIP:4.3ohm,5%,1/10W,DA,TP,2012
RP74 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608
RP75 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608
RP76 2007-000863 R-CHIP:4.3ohm,5%,1/10W,DA,TP,2012
RP77 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP78 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608
RP79 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
RP80 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
RP81 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP82 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP86 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP87 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP89 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP90 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608
RP91 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP93 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
RP95 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP96 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP98 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
RP99 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
RS01 2007-000781 R-CHIP;33ohm,5%,1/10W,DA,TP,2012 EIS only
RS02 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608 EIS only
RS03 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608 EIS only
RS04 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608 EIS only
RS05 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608 EIS only
RS06 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608 EIS only
RS07 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 EIS only
RS08 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608 EIS only
RS09 2007-001026 R-CHIP;560Kohm,5%,1/16W,DA,TP,1608 EIS only
RS10 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608 EIS only
RS11 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608 EIS only
RS13 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608 EIS only
RS14 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608 EIS only
RS15 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608 EIS only
RS16 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608 EIS only
RS17 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608 EIS only
RS18 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608 EIS only
RS19 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 EIS only
RS20 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608 EIS only
RS21 2007-001026 R-CHIP;560Kohm,5%,1/16W,DA,TP,1608 EIS only
RS22 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608 EIS only
RZ01 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 D.ZOOM
XP01 2801-001428 CRYSTAL-SMD;28.375MHz,30ppm,28-ABL,7pF,6
XP02 2801-003347 CRYSTAL-UNIT;17.734475MHz,20ppm,28-ABN,8
XP03 2801-003491 CRYSTAL-UNIT;32MHz,50ppm,28-ABL,9.2pF,60
DC/DC BLOCK
C901 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C902 2203-000512 C-CERAMIC,CHIP;2.2uF,+80-20%,16V,Y5V,321
C903 2404-000128 C-TA,CHIP;10uF,20%,16V,-,TP,6032,-
C904 2203-001724 C-CERAMIC,CHIP;4.7UF,+80-20%,16V,Y5V,321
C905 2404-000254 C-TA,CHIP;47uF,20%,10V,-,TP,7343,-
C906 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C907 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C908 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C909 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C910 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C911 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C912 2404-000120 C-TA,CHIP;10uF,20%,10V,-,TP,3528,-
C913 2404-000120 C-TA,CHIP;10uF,20%,10V,-,TP,3528,-
C915 2404-000120 C-TA,CHIP;10uF,20%,10V,-,TP,3528,-
C916 2203-000512 C-CERAMIC,CHIP;2.2uF,+80-20%,16V,Y5V,321
C917 2404-000120 C-TA,CHIP;10uF,20%,10V,-,TP,3528,-
C918 2203-000481 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,32
C919 2203-000481 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,32
C920 2203-000481 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,32
C921 2203-000481 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,32
C922 2203-000512 C-CERAMIC,CHIP;2.2uF,+80-20%,16V,Y5V,321
C923 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C924 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C925 2203-001559 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C926 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C927 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C928 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C929 2203-001636 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,1
C930 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608
C931 2203-001636 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,1
C932 2203-001632 C-CERAMIC,CHIP;330pF,5%,50V,CH,1608,1.6m
C933 2203-001640 C-CERAMIC,CHIP;390PF,10%,50V,X7R,TP,1608
C934 2203-002220 C-CERAMIC,CHIP;56PF,5%,50V,CH,TP,1608,-
C935 2203-001632 C-CERAMIC,CHIP;330pF,5%,50V,CH,1608,1.6m
C936 2203-001640 C-CERAMIC,CHIP;390PF,10%,50V,X7R,TP,1608
C937 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C938 2203-001636 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,1
C940 2203-000512 C-CERAMIC,CHIP;2.2uF,+80-20%,16V,Y5V,321
C941 2203-001103 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,1608
C942 2203-001103 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,1608
C943 2203-001609 C-CERAMIC,CHIP;22NF,10%,16V,X7R,TP,1608,
C944 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C945 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C946 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C949 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C950 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
D901 0404-000150 DIODE-SCHOTTKY;EC10QS04,40V,1A,SMD,TP
D902 0407-000139 DIODE-ARRAY;IMN10,80V,100mA,CX3,IMD,TP
IC901 1203-000445 IC-POSI.FIXED REG.;14641,TO-220,3P,-,PLA
L901 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L902 2703-000405 INDUCTOR-SMD;2.2UH,20%,3.2X2.5X2.2MM
L903 2703-000405 INDUCTOR-SMD;2.2UH,20%,3.2X2.5X2.2MM
L904 2703-001117 INDUCTOR-SMD;10uH,20%,7x7x3.2mm
L905 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm
L906 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L907 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L908 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm
L909 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm
L910 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm
Loc.No Part No Desc & Spec Remark Loc.No Part No Desc & Spec Remark
Electrical Parts List
Samsung Electronics
7-3
