L911 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L912 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L913 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L914 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L915 2703-001194 INDUCTOR-SMD;100uH,20%,7x7x3.2mm
L916 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L917 2703-001194 INDUCTOR-SMD;100uH,20%,7x7x3.2mm
L918 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L919 2703-000399 INDUCTOR-SMD;100uH,10%,3.2x2.5x2.2mm
L920 2703-000399 INDUCTOR-SMD;100uH,10%,3.2x2.5x2.2mm
L921 2703-000399 INDUCTOR-SMD;100uH,10%,3.2x2.5x2.2mm
Q901 0502-000432 TR-POWER;2SB1302-S,PNP,1.3W,SC-62,TP,14
Q902 0504-000113 TR-DIGITAL;DTC144EUA,NPN,200mW,47K-47K,S
Q903 0501-000172 TR-SMALL SIGNAL;2SB1121,PNP,500MW,PCP,TP
Q904 0501-000681 TR-SMALL SIGNAL;FP101,PNP,1.3W,PCP4,TP,1
Q905 0501-000681 TR-SMALL SIGNAL;FP101,PNP,1.3W,PCP4,TP,1
Q906 0501-000172 TR-SMALL SIGNAL;2SB1121,PNP,500MW,PCP,TP
Q907 0501-000172 TR-SMALL SIGNAL;2SB1121,PNP,500MW,PCP,TP
Q910 0504-000113 TR-DIGITAL;DTC144EUA,NPN,200mW,47K-47K,S
R901 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R902 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R903 2007-001699 R-CHIP;120Kohm,0.5%,1/16W,DA,TP,1608
R904 2007-001694 R-CHIP;12Kohm,0.5%,1/16W,DA,TP,1608
R905 2007-007202 R-CHIP;51Kohm,0.5%,1/16W,DA,TP,1608
R906 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R907 2007-007204 R-CHIP;5.1Kohm,0.5%,1/16W,DA,TP,1608
R908 2007-000766 R-CHIP;330ohm,5%,1/10W,DA,TP,2012
R910 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
R911 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608
R912 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
R913 2007-000766 R-CHIP;330ohm,5%,1/10W,DA,TP,2012
R914 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608
R915 2007-000101 R-CHIP;82Kohm,5%,1/16W,DA,TP,1608
R916 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
R917 2007-001643 R-CHIP;100Kohm,0.5%,1/16W,DA,TP,1608
R918 2007-001643 R-CHIP;100Kohm,0.5%,1/16W,DA,TP,1608
R919 2007-007203 R-CHIP;5.6Kohm,0.5%,1/16W,DA,TP,1608
R922 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
R923 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R924 2007-001695 R-CHIP;22Kohm,0.5%,1/16W,DA,TP,1608
R925 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R926 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R927 2007-001114 R-CHIP;680Kohm,5%,1/16W,DA,TP,1608
R929 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
R930 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
R931 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R932 2007-000081 R-CHIP;2.7Kohm,5%,1/16W,DA,TP,1608
R933 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R934 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R935 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R936 2007-000655 R-CHIP;27Kohm,5%,1/16W,DA,TP 200
R937 2007-000101 R-CHIP;82Kohm,5%,1/16W,DA,TP,1608
R940 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R941 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R942 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R943 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
R944 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R945 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R946 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R947 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
R948 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
T901 AD26-20120M TRANS-CONVERTOR;REEL,-,CMS64(285UH);S2C-
SYSCON/SERVO BLOCK
C401 2203-001573 C-CERAMIC,CHIP;12pF,5%,50V,CH,1608,1.6mm
C402 2203-001567 C-CERAMIC,CHIP;10pF,0.5pF,50V,CH,1608,1.
C403 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C404 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C421 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C431 2203-001559 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C432 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
C433 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
C434 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C435 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C436 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C501 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C502 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C503 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C504 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608
C505 2203-001609 C-CERAMIC,CHIP;22NF,10%,16V,X7R,TP,1608,
C506 2203-001609 C-CERAMIC,CHIP;22NF,10%,16V,X7R,TP,1608,
C507 2203-001559 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C508 2203-001559 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C509 2203-000062 C-CERAMIC,CHIP;47NF,+80-20%,50V,Y5V,1608
C510 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C511 2203-000062 C-CERAMIC,CHIP;47NF,+80-20%,50V,Y5V,1608
C512 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C515 2203-001640 C-CERAMIC,CHIP;390PF,10%,50V,X7R,TP,1608
C516 2203-000929 C-CERAMIC,CHIP;470PF,10%,50V,X7R,1608,-,
C517 2203-000062 C-CERAMIC,CHIP;47NF,+80-20%,50V,Y5V,1608
C524 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C525 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,1608,-,TP
C526 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,1608,-,TP
C528 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C529 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C530 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C531 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
C532 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C533 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C534 2203-000062 C-CERAMIC,CHIP;47NF,+80-20%,50V,Y5V,1608
C535 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608
C536 2203-001630 C-CERAMIC,CHIP;330nF,+80-20%,16V
C537 2203-002218 C-CERAMIC,CHIP;47NF,10%,16V,X7R,TP,1608,
C538 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
C539 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
C540 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
C541 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C542 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C543 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C544 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C545 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C546 2203-000199 C-CERAMIC,CHIP;100nF,+80-20%,50V,Z5U,TP,
C547 2402-000198 C-AL,SMD;47uF,20%,16V,GP,TP,6.3x5.4,-
C549 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C550 2203-001640 C-CERAMIC,CHIP;390PF,10%,50V,X7R,TP,1608
C552 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C553 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C554 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C555 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C601 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C602 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C603 2402-000182 C-AL,SMD;100uF,20%,6.3V,GP,TP,6.3x5.4,-
C604 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C605 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C606 2404-000232 C-TA,CHIP;4.7uF,20%,10V,WT,3216,-,TP
C608 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C609 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-
C610 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-
C611 2203-000384 C-CERAMIC,CHIP;15pF,5%,50V,NPO,TP,1608,-
C612 2203-000384 C-CERAMIC,CHIP;15pF,5%,50V,NPO,TP,1608,-
C613 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C614 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C615 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C617 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C618 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C625 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C626 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C627 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C628 2404-000259 C-TA,CHIP;47uF,20%,6.3V,-,TP,6032,-
C640 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CN501 3711-003366 CONNECTOR-HEADER;BOX,24P,2R,0.8mm,ANGLE,
CN502 3711-002046 CONNECTOR-HEADER;3WALL,12P,1R,1.25mm,SMD
CN503 3710-001301 CONNECTOR-SOCKET;48P,2R,0.8mm,SMD-S,SN
D402 0407-000115 DIODE-ARRAY;DAN202U,80V,100mA,CA2-3,SC-7
IC401 1204-001146 IC-OSD PROCESSOR;BU6251FV,SOP,20P,240MIL
IC421 1002-001070 IC-D/A CONVERTER;M62353GP,8BIT,SOP,16P,-
Loc.No
Part No Desc & Spec Remark
Loc.No
Part No Desc & Spec Remark
7-4
Samsung Electronics
Electrical Parts List
