Samsung SCL100 - Page 84

IC431 AC14-12012B IC;BA7046F-T1,SOP,-
IC501 AC14-12005J IC-LOGIC;KA8322,QFP,-
IC502 1003-001012 IC-MOTOR DRIVER;LB1950,SOP,30P,300MIL,SI
IC503 1003-001020 IC-MOTOR DRIVER;LB1951,SOP,24P,-,SINGLE,
IC504 1003-001146 IC-MOTOR DRIVER;LB1843VL,SOP,20P,-,-,800
IC601 AD09-10452C IC-MCU;CXP87240A-140Q,100P,QFP,VP-L10
IC602 1203-001123 IC-VOLTAGE REGULATOR;8420,SOP,8P,216MIL,
L401 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L402 2703-000372 INDUCTOR-SMD;56uH,5%,2.5x2x1.8mm
L421 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L431 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L601 2703-000399 INDUCTOR-SMD;100uH,10%,3.2x2.5x2.2mm
L602 2703-000399 INDUCTOR-SMD;100uH,10%,3.2x2.5x2.2mm
L603 2703-000399 INDUCTOR-SMD;100uH,10%,3.2x2.5x2.2mm
Q501 0501-000172 TR-SMALL SIGNAL;2SB1121,PNP,500MW,PCP,TP
Q502 0504-000110 TR-DIGITAL;DTC114EU,NPN,200mW,10K-10Kohm
Q602 0504-000194 TR-DIGITAL;DTC124EU,NPN,200MW,22K-22K,SC
Q604 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
Q605 0504-000107 TR-DIGITAL;DTA144EU,PNP,200mW,47K-47K,SC
R401 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R402 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R403 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R404 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R405 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R406 2007-000080 R-CHIP;2Kohm,5%,1/16W,DA,TP,1608
R407 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R408 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R409 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R410 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R411 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R412 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R413 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R415 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R431 2007-007352 R-CHIP;130KOHM,1%,1/16W,DA,TP,1608
R432 2007-000107 R-CHIP;470Kohm,5%,1/16W,DA,TP,1608
R433 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R434 2007-000107 R-CHIP;470Kohm,5%,1/16W,DA,TP,1608
R435 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
R501 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R502 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R503 2007-000065 R-CHIP;2.2Mohm,5%,1/16W,DA,TP,1608
R504 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R505 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R506 2007-000098 R-CHIP;56Kohm,5%,1/16W,DA,TP,1608
R507 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R508 2007-001114 R-CHIP;680Kohm,5%,1/16W,DA,TP,1608
R509 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R510 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R511 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
R512 2007-000087 R-CHIP;6.8Kohm,5%,1/16W,DA,TP,1608
R513 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
R514 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R515 2007-000093 R-CHIP;20Kohm,5%,1/16W,DA,TP,1608
R516 2007-000093 R-CHIP;20Kohm,5%,1/16W,DA,TP,1608
R517 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R518 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608
R519 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608
R523 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R524 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R525 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
R526 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R530 2007-000483 R-CHIP;1ohm,5%,1/10W,DA,TP,2012
R531 2007-000483 R-CHIP;1ohm,5%,1/10W,DA,TP,2012
R532 2007-000483 R-CHIP;1ohm,5%,1/10W,DA,TP,2012
R533 2007-000483 R-CHIP;1ohm,5%,1/10W,DA,TP,2012
R536 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R537 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R538 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R540 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R541 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R542 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R543 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
R544 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R545 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R550 2007-000503 R-CHIP;2.2ohm,5%,1/16W,DA,TP,1608
R551 2007-000503 R-CHIP;2.2ohm,5%,1/16W,DA,TP,1608
R552 2007-000503 R-CHIP;2.2ohm,5%,1/16W,DA,TP,1608
R559 2007-000130 R-CHIP;39Kohm,5%,1/16W,DA,TP,1608
R562 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
R563 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R570 2007-001643 R-CHIP;100Kohm,0.5%,1/16W,DA,TP,1608
R571 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608
R572 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608
R573 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R574 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R601 2007-001700 R-CHIP;330Kohm,0.5%,1/16W,DA,TP,1608
R602 2007-001693 R-CHIP;15Kohm,0.5%,1/16W,DA,TP,1608
R603 2007-001700 R-CHIP;330Kohm,0.5%,1/16W,DA,TP,1608
R604 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R605 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608
R606 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R607 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R608 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R609 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R611 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R612 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R614 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608
R615 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608
R616 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R617 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608
R618 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R619 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608
R620 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R622 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R623 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608
R625 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608
R626 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R627 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R628 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R629 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R630 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R631 2007-000290 R-CHIP;100ohm,5%,1/10W,DA,TP,2012
R632 2007-001644 R-CHIP;10Kohm,0.5%,1/16W,DA,TP,1608
R633 2007-001643 R-CHIP;100Kohm,0.5%,1/16W,DA,TP,1608
R634 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R635 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R638 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R639 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R640 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R641 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R642 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R643 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R644 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R646 2007-001643 R-CHIP;100Kohm,0.5%,1/16W,DA,TP,1608
R655 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R656 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R657 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R658 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R659 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R660 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R662 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R663 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R664 2007-001643 R-CHIP;100Kohm,0.5%,1/16W,DA,TP,1608
R665 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R667 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R668 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R669 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R670 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R671 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R672 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R673 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R674 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R675 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R676 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R677 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R678 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
Loc.No Part No Desc & Spec Remark Loc.No Part No Desc & Spec Remark
Electrical Parts List
Samsung Electronics
7-5
