Samsung SCL100 - Page 85

R679 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R683 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R684 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R686 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R687 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R689 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R690 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R691 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R692 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R697 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
SW501 AD34-20100B SWITCH-MODE;8EA,13MM/6.5MM,REEL,3V
SW502 3403-000126 SWITCH-PUSH;12V,100MA,-,-
XT601 2801-001449 CRYSTAL-SMD;32.768KHZ,20PPM,28-AAW,12.5P
XT602 2801-003239 CRYSTAL-SMD;11.71875MHz,50ppm,28-ABL,13p
VIDEO BLOCK
C101 2203-001609 C-CERAMIC,CHIP;22NF,10%,16V,X7R,TP,1608,
C102 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C103 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C104 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C105 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C106 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C107 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C108 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C109 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C110 2203-001559 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C111 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C112 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C113 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C114 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C115 2203-001559 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C116 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C117 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C118 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C120 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C121 2203-001559 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C122 2203-000357 C-CERAMIC,CHIP;150pF,5%,50V,NPO,TP,1608,
C123 2203-001686 C-CERAMIC,CHIP;75PF,5%,50V,CH,TP,1608,1.
C124 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C125 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C126 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C151 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C152 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C153 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C154 2203-001573 C-CERAMIC,CHIP;12pF,5%,50V,CH,1608,1.6mm
C155 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C156 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
C157 2203-001609 C-CERAMIC,CHIP;22NF,10%,16V,X7R,TP,1608,
C158 2203-001676 C-CERAMIC,CHIP;62PF,5%,50V,CH,TP,1608,1.
C159 2203-001616 C-CERAMIC,CHIP;270pF,5%,50V,CH,1608,1.6m
C163 2203-001588 C-CERAMIC,CHIP;18pF,5%,50V,CH,1608,1.6mm
C164 2203-000384 C-CERAMIC,CHIP;15pF,5%,50V,NPO,TP,1608,-
C165 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C166 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C167 2203-001609 C-CERAMIC,CHIP;22NF,10%,16V,X7R,TP,1608,
C168 2203-001636 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,1
C201 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C202 2203-001640 C-CERAMIC,CHIP;390PF,10%,50V,X7R,TP,1608
C203 2203-001632 C-CERAMIC,CHIP;330pF,5%,50V,CH,1608,1.6m
C204 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C205 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C206 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C207 2203-000357 C-CERAMIC,CHIP;150pF,5%,50V,NPO,TP,1608,
C208 2203-001607 C-CERAMIC,CHIP;220pF,5%,50V,CH,1608,1.6m
C209 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C211 2203-001697 C-CERAMIC,CHIP;82PF,5%,50V,CH,TP,1608,1.
C212 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C214 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C215 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C216 2404-000166 C-TA,CHIP;2.2uF,20%,10V,-,TP,3216,-
C217 2404-000166 C-TA,CHIP;2.2uF,20%,10V,-,TP,3216,-
C218 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C219 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C220 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C221 2203-000357 C-CERAMIC,CHIP;150pF,5%,50V,NPO,TP,1608,
C222 2203-001573 C-CERAMIC,CHIP;12pF,5%,50V,CH,1608,1.6mm
C223 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C224 2203-000919 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP,
C225 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C226 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C227 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C228 2203-001402 C-CERAMIC,CHIP;220nF,+80-20%,16V
C229 2404-000232 C-TA,CHIP;4.7uF,20%,10V,WT,3216,-,TP
C230 2402-001008 C-AL,SMD;220uF,20%,4V,-,6.6x6.6x5.4mm,2
C231 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C232 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
C233 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C234 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C236 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C237 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C238 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C239 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C241 2203-001658 C-CERAMIC,CHIP;47pF,5%,50V,CH,1608,1.6mm
C242 2203-001568 C-CERAMIC,CHIP;110PF,5%,50V,CH,TP,1608,1
C243 2203-001588 C-CERAMIC,CHIP;18pF,5%,50V,CH,1608,1.6mm
C244 2203-000851 C-CERAMIC,CHIP;39PF,5%,50V,NPO,TP,1608,-
C245 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,1608,-,TP
C246 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
C247 2203-001103 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,1608
C248 2203-001609 C-CERAMIC,CHIP;22NF,10%,16V,X7R,TP,1608,
C249 2404-000261 C-TA,CHIP;680nF,20%,20V,-,TP,3216,-
C250 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,1608,-,TP
C251 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C254 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C255 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C256 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C257 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C258 2404-000232 C-TA,CHIP;4.7uF,20%,10V,WT,3216,-,TP
C259 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C260 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C261 2203-001658 C-CERAMIC,CHIP;47pF,5%,50V,CH,1608,1.6mm
C262 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C263 2203-001636 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,1
C264 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C265 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C266 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C267 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C268 2203-001658 C-CERAMIC,CHIP;47pF,5%,50V,CH,1608,1.6mm
C269 2203-000062 C-CERAMIC,CHIP;47NF,+80-20%,50V,Y5V,1608
C270 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-
C285 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C286 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C291 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C301 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C302 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C303 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C304 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C306 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C307 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C308 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C309 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,1608,-,TP
C310 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,1608,-,TP
C311 2203-001588 C-CERAMIC,CHIP;18pF,5%,50V,CH,1608,1.6mm
C312 2203-001618 C-CERAMIC,CHIP;27pF,5%,50V,CH,1608,1.6mm
C313 2203-001559 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C314 2203-001618 C-CERAMIC,CHIP;27pF,5%,50V,CH,1608,1.6mm
C315 2203-001618 C-CERAMIC,CHIP;27pF,5%,50V,CH,1608,1.6mm
C316 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-
C317 2203-001658 C-CERAMIC,CHIP;47pF,5%,50V,CH,1608,1.6mm
C318 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-
C319 2203-001559 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C320 2203-001658 C-CERAMIC,CHIP;47pF,5%,50V,CH,1608,1.6mm
C321 2203-001658 C-CERAMIC,CHIP;47pF,5%,50V,CH,1608,1.6mm
C322 2203-001567 C-CERAMIC,CHIP;10pF,0.5pF,50V,CH,1608,1.
C323 2203-001567 C-CERAMIC,CHIP;10pF,0.5pF,50V,CH,1608,1.
C324 2203-001683 C-CERAMIC,CHIP;68PF,5%,50V,CH,TP,1608,1.
Loc.No Part No Desc & Spec Remark Loc.No Part No Desc & Spec Remark
7-6
Samsung Electronics
Electrical Parts List
