Samsung SCL100 - Page 87

R209 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
R210 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R213 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R214 2007-000839 R-CHIP;39ohm,5%,1/16W,DA,TP,1608
R215 2007-000839 R-CHIP;39ohm,5%,1/16W,DA,TP,1608
R216 2007-000043 R-CHIP;1Kohm,1%,1/16W,DA,TP,1608
R217 2007-000043 R-CHIP;1Kohm,1%,1/16W,DA,TP,1608
R218 2007-001179 R-CHIP;8.2Kohm,5%,1/16W,DA,TP,1608
R219 2007-000130 R-CHIP;39Kohm,5%,1/16W,DA,TP,1608
R220 2007-000130 R-CHIP;39Kohm,5%,1/16W,DA,TP,1608
R221 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608
R222 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608
R223 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R224 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
R225 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608
R226 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R227 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608
R228 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R231 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
R232 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608
R233 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R234 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R236 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
R237 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R238 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
R239 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R240 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
R243 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R244 2007-000120 R-CHIP;680ohm,5%,1/16W,DA,TP,1608
R246 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R247 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R248 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R249 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R250 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R251 2007-000120 R-CHIP;680ohm,5%,1/16W,DA,TP,1608
R252 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R253 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R254 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R255 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R256 2007-001179 R-CHIP;8.2Kohm,5%,1/16W,DA,TP,1608
R257 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R258 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608
R259 2007-000093 R-CHIP;20Kohm,5%,1/16W,DA,TP,1608
R261 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R262 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R263 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R264 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R265 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R266 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R267 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R268 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
R269 2007-000120 R-CHIP;680ohm,5%,1/16W,DA,TP,1608
R270 2007-000120 R-CHIP;680ohm,5%,1/16W,DA,TP,1608
R271 2007-000118 R-CHIP;390ohm,5%,1/16W,DA,TP,1608
R272 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R273 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R274 2007-000120 R-CHIP;680ohm,5%,1/16W,DA,TP,1608
R275 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R276 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R277 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R278 2007-000081 R-CHIP;2.7Kohm,5%,1/16W,DA,TP,1608
R279 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R280 2007-000121 R-CHIP;820ohm,5%,1/16W,DA,TP,1608
R281 2007-000121 R-CHIP;820ohm,5%,1/16W,DA,TP,1608
R283 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608
R284 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R285 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R286 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R287 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R288 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R291 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R292 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R294 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R295 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
R302 2007-001026 R-CHIP;560Kohm,5%,1/16W,DA,TP,1608
R303 2007-000120 R-CHIP;680ohm,5%,1/16W,DA,TP,1608
R304 2007-000512 R-CHIP;2.4Kohm,5%,1/16W,DA,TP,1608
R305 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R306 2007-001134 R-CHIP;68ohm,5%,1/16W,DA,TP,1608
R307 2007-000643 R-CHIP;270ohm,5%,1/16W,DA,TP,1608
R308 2007-000120 R-CHIP;680ohm,5%,1/16W,DA,TP,1608
R309 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
R310 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R311 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
R312 2007-000120 R-CHIP;680ohm,5%,1/16W,DA,TP,1608
R313 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608
R314 2007-000839 R-CHIP;39ohm,5%,1/16W,DA,TP,1608
R315 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R316 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R317 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R319 2007-000121 R-CHIP;820ohm,5%,1/16W,DA,TP,1608
R320 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R321 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R322 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R326 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R329 2007-000101 R-CHIP;82Kohm,5%,1/16W,DA,TP,1608
R330 2007-000116 R-CHIP;120ohm,5%,1/16W,DA,TP,1608
R331 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R332 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R335 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R336 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R339 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R351 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R352 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R353 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
R354 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R355 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R356 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R357 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R358 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R359 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R360 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R361 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R362 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R364 2007-000121 R-CHIP;820ohm,5%,1/16W,DA,TP,1608
R366 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R367 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
R368 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R369 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R371 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R381 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R382 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R396 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608
X201 2801-003240 CRYSTAL-SMD;4.433619MHz,20ppm,28-ABN,SER
154 AD90-10828G ASSY-CCD BOARD;VP-L10,S8C-PAL-CCD VP-L100/VP-L150
154 AD90-10831H ASSY-CCD BOARD;SC-L100/BASIC,NTSC 3 SCL150/SCL100
CC01 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,1608,-,
CC02 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CC03 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,3528,-,TP
CC04 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CC05 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,3528,-,TP
CC06 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CC07 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CC10 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,3528,-,TP
CNC01 3711-003315 CONNECTOR-HEADER;BOX,18P,2R,0.8MM,SMD-A,
DC01 0401-000171 DIODE-SWITCHING;MA111,80V,100mA,-,3nS,SM
DC02 0401-000171 DIODE-SWITCHING;MA111,80V,100mA,-,3nS,SM
LC01 2703-000399 INDUCTOR-SMD;100uH,10%,3.2x2.5x2.2mm
QC01 0505-000180 FET-SILICON;2SK1070PIETR,-,150MW,SOT
RC01 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
RC02 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RC03 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608
RC05 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RC06 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
Loc.No Part No Desc & Spec Remark Loc.No Part No Desc & Spec Remark
7-8
Samsung Electronics
Electrical Parts List
