198 AD90-10810Q ASSY-EVF BOARD;VP-L90,PAL VP-L100/VP-L150
198 AD90-10810R ASSY-EVF BOARD;SCL90,NTSC SCL150/SCL100
CE01 2203-000308 C-CERAMIC,CHIP;120PF,5%,50V,NPO,TP,1608,
CE02 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
CE03 2404-000112 C-TA,CHIP;100uF,20%,6.3V,WT,7343,-,TP
CE04 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608
CE05 2404-000175 C-TA,CHIP;2.2uF,20%,6.3V,WT,3216,1.1mm,T
CE06 2306-000116 C-FILM,MPPF;100nF,5%,16V,C3225,2.5mm,TP
CE07 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE08 2404-000128 C-TA,CHIP;10uF,20%,16V,-,TP,6032,-
CE09 2203-000357 C-CERAMIC,CHIP;150pF,5%,50V,NPO,TP,1608,
CE10 2402-000144 C-AL,SMD;3.3uF,20%,50V,GP,4x5.4mm,-,TP
CE11 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
CE12 2404-000112 C-TA,CHIP;100uF,20%,6.3V,WT,7343,-,TP
CE13 2404-000112 C-TA,CHIP;100uF,20%,6.3V,WT,7343,-,TP
CE14 2404-000112 C-TA,CHIP;100uF,20%,6.3V,WT,7343,-,TP
CE15 2309-000143 C-FILM,CHIP;3.9nF,5%,100V,-,-,TP
CE16 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE17 2402-000144 C-AL,SMD;3.3uF,20%,50V,GP,4x5.4mm,-,TP
CNE01 3711-000862 CONNECTOR-HEADER;BOX,3P,1R,1.25mm,SMD-A,
CNE02 3711-002173 CONNECTOR-HEADER;BOX,4P,1R,1.5,STRAIGHT,
DE01 0407-000151 DIODE-ARRAY;MA153,40V,100mA,C2-3,SOT-23,
DE02 0401-000173 DIODE-SWITCHING;MA151K,40V,100mA,-,3nS,S
DE03 0401-000166 DIODE-SWITCHING;MA158-TX,200V,100mA,-,-,
ICE01 AC14-12006W IC-LINEAR;KA7007,SOP,-
LE01 2703-000409 INDUCTOR-SMD;47uH,10%,3.2x2.5x2.2mm
QE01 0501-000674 TR-SMALL SIGNAL;2SA1179,PNP,200MW,SOT-23
QE02 0501-000238 TR-SMALL SIGNAL;2SD968A,NPN,1W,SC-62,-,1
QE03 0501-000674 TR-SMALL SIGNAL;2SA1179,PNP,200MW,SOT-23
RE01 2007-000637 R-CHIP;270Kohm,5%,1/16W,DA,TP,1608
RE02 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608
RE03 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
RE04 2007-000107 R-CHIP;470Kohm,5%,1/16W,DA,TP,1608
RE05 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RE06 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RE07 2007-000637 R-CHIP;270Kohm,5%,1/16W,DA,TP,1608
RE08 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RE09 2007-000695 R-CHIP;3.3ohm,5%,1/16W,DA,TP,1608
RE10 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608
RE11 B1335-0002 THERMISTOR-CHIP;NTC CS 3216 3BH 471KC 47
RE12 2007-000931 R-CHIP;470ohm,5%,1/10W,DA,TP,2012
RE13 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RE14 2007-000081 R-CHIP;2.7Kohm,5%,1/16W,DA,TP,1608
RE15 2007-000965 R-CHIP;5.1Kohm,5%,1/16W,DA,TP,1608
RE16 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RE17 2007-001056 R-CHIP;6.2Kohm,5%,1/16W,DA,TP,1608
RE18 2007-000101 R-CHIP;82Kohm,5%,1/16W,DA,TP,1608
RE19 2007-001179 R-CHIP;8.2Kohm,5%,1/16W,DA,TP,1608
RE20 2007-000130 R-CHIP;39Kohm,5%,1/16W,DA,TP,1608
RE21 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RE22 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
RE23 2007-000029 R-CHIP;0ohm,5%,1/10W,DA,TP,2012
RE24 2007-000029 R-CHIP;0ohm,5%,1/10W,DA,TP,2012
RE25 2007-000689 R-CHIP;3.3MOHM,5%,1/10W,DA,TP,2012
RE26 2007-000689 R-CHIP;3.3MOHM,5%,1/10W,DA,TP,2012
RE27 2007-000462 R-CHIP;18ohm,5%,1/10W,DA,TP,2012
VRE01 2104-001014 VR-SMD;50KOHM,25%,0.15W,TOP
VRE02 2104-001013 VR-SMD;220ohm,25%,0.15W,TOP
VRE03 2104-000178 VR-SMD;1MOHM,30%,1/20W,TOP
CE18 2201-000911 C-CERAMIC,DISC;1.2NF,10%,1KV,Y5P,BK,10X5
CNE03 AC03-12001B SOCKET-CRT;SOCKET FINDER,PI10 40MM,-,-,-
FTB01 AC26-32001B TRANS-FLYBACK;ECX-C2806D,0.6INCH,4.8V
LE02 AC27-32001B COIL-LINEARITY;230UH-15%,PI0.12,T,-,-
141 AD90-10828B ASSY-LCD BOARD;VP-L100,PAL 3 VP-L100/VP-L150
141 AD90-10831J ASSY-LCD BOARD;SC-L100/BASIC,NTSC 3 SCL150/SCL100
CL101 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL102 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL103 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL104 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL105 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
CL106 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
CL107 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,3528,-,TP
CL108 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
CL109 2404-000159 C-TA,CHIP;1uF,20%,35V,-,TP,3528,-
CL110 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,3528,-,TP
CL137 2404-000112 C-TA,CHIP;100uF,20%,6.3V,WT,7343,-,TP
CL138 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL148 2301-001051 C-FILM,CHIP;56nF,5%,50V,TP,4.8X3.3X1.4,0
CL150 2203-005233 C-CERAMIC,CHIP;27PF,5%,3KV,CH,TP,4520,-
CL157 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CL158 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL160 2404-000112 C-TA,CHIP;100uF,20%,6.3V,WT,7343,-,TP
CL161 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL201 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL203 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
CL204 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL207 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
CL208 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CL209 2203-001103 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,1608
CL210 2404-000167 C-TA,CHIP;2.2uF,20%,16V,-,TP,3216,-
CL211 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CL212 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CL213 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CL214 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CL215 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CL216 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CL217 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CL218 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CL219 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CL221 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
CL224 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
CL225 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
CL226 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
CL227 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CL228 2203-001121 C-CERAMIC,CHIP;680PF,10%,50V,X7R,1608,-,
CL229 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL230 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CL231 2203-002220 C-CERAMIC,CHIP;56PF,5%,50V,CH,TP,1608,-
CL232 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CL233 2203-000062 C-CERAMIC,CHIP;47NF,+80-20%,50V,Y5V,1608
CL234 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CL235 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CL236 2203-001697 C-CERAMIC,CHIP;82PF,5%,50V,CH,TP,1608,1.
CL237 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL239 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CL240 2404-000250 C-TA,CHIP;470nF,20%,25V,-,TP,3216,-
CL242 2203-001688 C-CERAMIC,CHIP;7PF,0.5PF,50V,CH,TP,1608,
CL245 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-
CL304 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
CL309 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL310 2203-001703 C-CERAMIC,CHIP;560PF,10%,50V,X7R,TP,1608
CL311 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL312 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,1608,-,TP
CL313 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL314 2203-001697 C-CERAMIC,CHIP;82PF,5%,50V,CH,TP,1608,1.
CL315 2404-000232 C-TA,CHIP;4.7uF,20%,10V,WT,3216,-,TP
CL316 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CL317 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL318 2404-000128 C-TA,CHIP;10uF,20%,16V,-,TP,6032,-
CL319 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL324 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL325 2203-000199 C-CERAMIC,CHIP;100nF,+80-20%,50V,Z5U,TP,
CL326 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL327 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL328 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL329 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
CL331 2404-000133 C-TA,CHIP;10uF,20%,25V,-,TP,7343,-
CL340 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CNL102 3708-000402 CONNECTOR-FPC/FC/PIC;10P,0.8MM,ANGLE,SN
CNL201 3708-001184 CONNECTOR-FPC/FC/PIC;18P,0.8mm,SMD-A,SN
CNL301 3708-001181 CONNECTOR-FPC/FC/PIC;26P,0.5MM,SMD-A,SN
DL302 0405-000123 DIODE-VARACTOR;1T369,34V,10nA,DSM,TP
DL303 0401-000171 DIODE-SWITCHING;MA111,80V,100mA,-,3nS,SM
ICL101 1201-001086 IC-OP AMP;75S558,SOP,5P,62.9MIL,DUAL,100
Loc.No
Part No Desc & Spec Remark
Loc.No
Part No Desc & Spec Remark
Electrical Parts List
Samsung Electronics
7-9
