9-2 Samsung Electronics
Schematic Diagrams
OPTION LIST
NORMAL
NORMALHi8 Hi8
NO LOC VALUE(BASIC) SCL500 SCL520 SCL530 SCL550 VP-L500 VP-L520 VP-L530 VP-L530B VP-L550 OPTION
NORMAL
NORMALHi8 Hi8
NO LOC VALUE(BASIC) SCL500 SCL520 SCL530 SCL550 VP-L500 VP-L520 VP-L530 VP-L530B VP-L550 OPTION
1 C156 120,50V,* O O O - X X X X - NTSC
150,50V,* X X X - O O O O - PAL
2 C201 120,50V,* X X X - O O O O - PAL
150,50V,* O O O - X X X X - NTSC
3 C220 103,50V,* - - - X - - - - X TUNER
4 C223 103,50V,* X X X - O O O O - PAL
471,50V,* O O O - X X X X - NTSC
5 C224 332,50V,* X X X - O O O O - PAL
221,50V,* O O O - X X X X - NTSC
6 C231 120,50V,* - - - X - - - - O PAL
150,50V,* - - - O - - - - X NTSC
7 C233 151,50V,* O O O - - - - - - NTSC
820,50V,* X X X - O O O O - PAL
8 C249 103,50V,* X X X - X X X X - None
9 C250 103,50V,* X X X - X X X X - None
10 C251 103,50V,* X X X - X X X X - None
11 C252 103,50V,* X X X - X X X X - None
12 C263 103,50V,* - - - X - - - - O PAL
221,50V,* - - - O - - - - X NTSC
13 C264 332,50V,* - - - - - - - - O PAL
471,50V,* - - - O - - - - X NTSC
14 C281 470nF,25V,* X X X - X X X X - Normal
680,50V,* - - - O - - - - O Hi8
15 C282 470nF,25V,* X X X - X X X X - None
16 C283 121,50V,* - - - O - - - - O NTSC/PAL
17 C543 472,50V,* O O O O X X X X X NTSC
562,50V,* X X X X O O O O O PAL
18 C544 392,50V,* O O O O X X X X X NTSC
472,50V,* X X X X O O O O O PAL
19 C550 4.7/10V* O O O O O O O O O BUFFER O
20 C551 4.7/10V* O O O O O O O O O BUFFER O
21 C603 10/10V, X X X X X X X X X None
22 C609 102,50V,* O O O O O O O O O M2
23 C610 102,50V,* O O O O O O O O O M2
24 C724 10/10V, O O O O O O O O O LCD-B&W
25 C725 47/6.3V, O O O O O O O O O LCD-B&W
26 C726 10/10V, O O O O O O O O O LCD-B&W
27 C727 0.68/25V, O O O O O O O O O LCD-B&W
28 C733 105,25V,* X X X X X X X X X None
29 C740 104,25V,* X X X X X X X X X None
30 C761 10/10V, X X O O X O O O O REMOCON O
31 C908 10/10V, O O O O O O O O O LCD-B&W
32 C909 105,25V,* O O O O O O O O O LCD-B&W
33 C918 105,25V,* O O O O O O O O O LCD-B&W
34 C919 105,25V,* O O O O O O O O O LCD-B&W
35 C942 102,50V,* X X X X X X X X X None
36 C943 102,50V,* X X X X X X X X X None
37 C944 10/16V, X X X X X X X X X None
38 CD03 22/10V, X X O O X X O O O DIS O
39 CD04 104,25V,* X X O O X X O O O DIS O
40 CD05 104,25V,* X X O O X X O O O DIS O
41 CD06 104,25V,* X X O O X X O O O DIS O
42 CD07 104,25V,* X X O O X X O O O DIS O
43 CD08 104,25V,* X X O O X X O O O DIS O
44 CD09 104,25V,* X X O O X X O O O DIS O
45 CD10 22/10V, X X O O X X O O O DIS O
46 CD11 104,25V,* X X O O X X O O O DIS O
47 CD12 105,25V,* X X O O X X O O O DIS O
48 CP64 220,50V,* O O O O O O O O O NORMAL
49 CP67 180,50V,* X X X X O O O O O PAL
270,50V,* O O O O X X X X X NTSC
50 CP78 103,50V,* O O O O O O O O O LCD-B&W
51 CW01 104,25V,* X X X O X X X X O XDR O
52 CW02 10/10V, X X X O X X X X O XDR O
53 CW03 104,25V,* X X X O X X X X O XDR O
54 CW04 104,25V,* X X X O X X X X O XDR O
55 D902 85V,300mA,* X X X X X X X X X None
56 D903 KDS160,85V,* O O O O O O O O O LCD-B&W
57 IC281 NJM2249V,NONE,* X X X X X X X X X None
58 IC401 M35040-064FP,150mW,* O O O - O O O O - EXP
59 IC431 M35040-064FP,150mW,* - - - O - - - - O EXP
60 IC601 CXP874P60R-1,100P,* X X X X O O O O O PAL
CXP874P60R-1,100P,* O O O O X X X X X NTSC
61 ICD01 KM416S1120,TSOP,* X X O O X X O O O DIS O
62 ICD02 KS7333,QFP,* X X O O X X O O O DIS O
63 ICD03 TC7S08FU,NONE,* X X O O X X O O O DIS O
64 ICW01 KS7332B,VQFP,* X X X O X X X X O XDR O
65 L281 10uH,5%,* - - - O - - - - O NTSC/PAL
66 L351 33uH,10%,* X X X X X X X X X None
67 L702 100uH,NONE,* O O O O O O O O O LCD-B&W
68 L906 10uH,10%,* O O O O O O O O O LCD-B&W
69 L907 6.8UH,NONE,* O O O O O O O O O LCD-B&W
70 L913 33uH,10%,* O O O O O O O O O LCD-B&W
71 L923 33UH,NONE,* X X X X X X X X X None
72 LD01 22uH,NONE,* X X O O X X O O O DIS O
73 LD02 22uH,10%,* X X O O X X O O O DIS O
74 Q220 UMX2,50V,* - - - X - - - - X Hi8
75 Q222 UMX2,50V,* X X X - X X X X - Normal
76 Q225 2SC4081,200mW,* - - - X - - - - X Hi8
77 Q241 KTA2014,100mW,* - - - X - - - - X Hi8
78 Q242 KRC404,100mW,* - - - X - - - - X Hi8
79 Q269 2SC4081,200mW,* - - - X - - - - X Hi8
80 Q283 2SC4081,200mW,* X X X - X X X X - Normal
81 Q353 KTA2014,100mW,* X X X - X X X X - Normal
82 Q354 KRC404,100mW,* X X X - X X X X - Normal
83 Q504 UMX2,50V,* O O O O O O O O O BUFFER O
84 Q602 KRC404,100mW,* X X X X X X X X X None
85 Q701 KTA1298,PNP,* O O O O O O O O O LCD-B&W
86 Q702 KRC402,100MW,* X X X O O O O O O LCD-B&W
87 Q761 100mW,47K/47Kohm,* X X O O X O O O O REMOCON O
88 Q762 2SC4081,200mW,* X X O O X O O O O REMOCON O
89 Q904 100mW,4.7K,* X X X X X X X X X None
90 Q905 100mW,4.7K,* X X X X X X X X X None
91 Q910 FP101,1.3W,* X X X X X X X X X None
92 QP07 2SB970R,200mW,* O O O O O O O O O LCD-B&W
93 R024 680,(1/16W),* - - - - - - - - O PAL
3.3K,(1/16W),* - - - O - - - - - NTSC
94 R159 1.2K,(1/16W),* O O O - X X X X - NTSC
750(1/16W),* X X X - O O O O - PAL
95 R162 330,(1/16W),* X X X - O O O O - PAL
470,(1/16W),* O O O - X X X X - NTSC
96 R163 330,(1/16W),* O O O - O O O O - NTSC/PAL
97 R206 560,(1/16W),* O O O - X X X X - NTSC
680,(1/16W),* X X X - O O O O - PAL
98 R211 3.3K,(1/16W),* O O O - X X X X - NTSC
2.2K,(1/16W),* X X X - O O O O - PAL
99 R216 000,(1/16W),* - - - X - - - - X Hi8
100 R223 3.3K,(1/16W),* - - - X - - - - X Hi8
101 R225 15K,(1/16W),* - - - X - - - - X HI8
102 R226 10K,(1/16W),* - - - X - - - - X HI8
103 R230 1K,(1/16W),* X X X - X X X X - Normal
104 R231 1.5K,(1/16W),* X X X - X X X X - Normal
