Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
110 AD97-01106A ASSY-CAMERA;M-P/J,-,X22,270K,NTSC/NOR SCL500
AD97-02091A ASSY-CAMERA;-,M-P/J,SAMSUNG,PAL/NORMAL VP-L500/L520/L530
AD97-02092A ASSY-CAMERA;-,M-P/J,SAMSUNG,NTSC/NORMAL SCL520/L530
AD97-02093A ASSY-CAMERA;-,M-P/J,SAMSUNG,NTSC/Ni SCL550
AD97-02094A ASSY-CAMERA;-,M-P/J,SAMSUNG,PAL/Ni VP-L550
113 AD97-01111A ASSY-CCD BOARD;M-P/J,NTSC,-,NOR,270K SCL500
AD97-02099A ASSY-CCD BOARD,C;-,M-P/J,LENS by KOREA SCL520/L530/L550
VP-L500/L520/L530/L530B/L550
114 AD60-00034A SPACER-CCD;-,-,-,-,BLK,M1-PJ SCL500/L520/L530
VP-L500/L520/L530/L530B
AD63-62008A SPACER-CCD;-,SILICON,22X,-,-,SC-L350 SCL550/VP-L550
115 AD61-00215A BRACKET-LENS(22X);-,-,-,T0.5,-,SUS304,M1 ALL
116 AD97-02095A ASSY-LENS;-,M-P/J,SAMSUNG,PAL/NORMAL VP-L500/L520/L530/L530B
AD97-02096A ASSY-LENS;-,M-P/J,SAMSUNG,NTSC/NORMAL SCL520/L530
AD97-02097A ASSY-LENS;-,M-P/J,SAMSUNG,NTSC/Hi SCL550
AD97-02098A ASSY-LENS;-,M-P/J,SAMSUNG,PAL/Hi VP-L550
117 AD67-00034A LENS-ZOOM;-,-,64.39X39.6,5V,-,CS2000,-,2 SCL500
120 AD61-00222A CHASSIS-TOP;-,SUS304,-,T0.5,-,-,-,-,-,M1 ALL
121 AD61-00321A CHASSIS-BOTTOM;-,SUS304,-,T0.5,-,-,-,-,D ALL
125 AD97-01624A ASSY-FPC ROTARY;VP-M52,-,M-PJ DE-6D ALL
126 AD92-00005A ASSY PCB-DECK FPC;M-PJ DE-6D,DECK FPC ALL
186 AD94-00129A ASSY-MAIN BOARD;VP-L520,PAL VP-L520
AD94-00130A ASSY-MAIN BOARD;VP-L530,PAL VP-L530/L530B
AD94-00131A ASSY-MAIN BOARD;VP-L550,PAL VP-L550
AD94-00132A ASSY-MAIN BOARD;SC-L520,NTSC SCL520
AD94-00133A ASSY-MAIN BOARD;SC-L540,NTSC SCL530
AD94-00134A ASSY-MAIN BOARD;SC-L550,NTSC SCL550
AD94-00142A ASSY-MAIN BOARD;VP-L500/XEU,M2-PJ VP-L500
AD94-00148A ASSY-MAIN BOARD;SC-L500/XAC,M2-PJ SCL500
250 AD64-00174A CASE-TOP;-,ABS 94HB,-,-,-,-,-,M1-PJ ALL
500 AD97-01691A ASSY-DECK;DE-6E,-,DECK SCL550/VP-L550
AD97-01694A ASSY-DECK;DE-6E,-,PAL VP-L500/L520/L530/L530B
AD97-01695A ASSY-DECK;DE-6E,-,NTSC SCL500/L520/L530
901 AC60-10017A SCREW-MACHINE;BH,+,M1.7,X3.5,FEFZY,SWCH1 ALL
904 AC60-10055A SCREW-TAPPING;BH,+,-,M2,X4,FZB ALL
905 AC60-10054A SCREW-TAPPING;BH,+,-,M2,X6,FZB ALL
907 AC60-10024A SCREW-MACHINE;BH,+,M2,X3,FZW,FE,-,-,- ALL
