NO-OSD-DISPLAY DISTANCE
ADDR MODEL/DATA CONTENT
NTSC PAL
NOR HI8 NOR HI8 D7 D6 D5 D4 D3 D2 D1 D0
PAL NTSC
001 40 - 40 - CAMERA OPTION ; NON I-BLC VP-L500,L520,L530 SCL500,L520
50 50 50 50 CAMERA OPTION ; I-BLC VP-M550(HI-8) SCL530,L550(HI8)
05A 08 - 0C - DIGITAL CLAMP AT AGC ON(#118-#05A); NON-DIS VP-L500,L520 SCL500,L520
00 00 00 00 DIGITAL CLAMP AT AGC ON(#118-#05A); DIS MODE VP-L530,L550(HI-8) SCL530,L550(HI8)
07E E7 - - - D.ZOOM RATIO MAX ; X220 - SCL500
F4 F4 F4 F4 D.ZOOM RATIO MAX ; X440 VP-L500,L520,L530,L550(HI8) SCL520,L530,L550(HI8)
104 07 - 08 - GLOVAL DELAY : NON I-BLC, NON-DIS VP-L500,L520 SCL500,L520
- - 08 - GLOVAL DELAY ; NON I-BLC DIS VP-L530 -
18 0C - 0C GLOVAL DELAY ; I-BLC,DIS VP-L550(HI8) SCL530,L550(HI8)
118 08 - 0D - DIGITAL CLAMP ; NON-DIS VP-L500,L520 SCL500,L520
00 00 00 00 DIGITAL CLAMP ; DIS VP-L530,L550(HI8) SCL530,L550(HI8)
134 0A - 04 - R-DARK-SLICE ; NON-DIS VP-L500,L520 SCL500,L520
0A 05 09 09 R-DARK-SLICE ; DIS VP-L530,L550(HI8) SCL530,L550(HI8)
135 FA - 07 - B-DARK-SLICE ; NON-DIS VP-L500,L520 SCL500,L520
00 FE FD 00 B-DARK-SLICE ; DIS VP-L530,L550(HI8) SCL530,L550(HI8)
Samsung Electronics 4-21
Alignment and Adjustment
NO-OSD-DISPLAY DISTANCE
ADDR MODEL/DATA CONTENT
NTSC PAL
NOR HI8 NOR HI8 D7 D6 D5 D4 D3 D2 D1 D0
274 0C 0D 0D 0D |---- POFFSET (7:0) DIGITAL CLAMP OFFSET VALUE FROM MICOM ----|
275 03 03 03 03 |---- PCMD (7:0) PREPROCESS COMMAND FROM MICOM ----|
276 00 00 00 00 |---- PRAMIL (7:0) DEFECT POSITION VALUE(7:0) FROM MICOM ----|
277 00 00 00 00 |---- PRAMIM (16:8) DEFECT POSITION VALUE(15:8) FROM MICOM ----|
278 00 00 00 00 X X X X PRAMIM (19:16) DEFECT POSITION FROM MICOM
279 00 00 00 00 X X |----PRAMA_MI (5:0) LINE MEMORY ADDRESS FROM MICOM ----|
27A 00 00 00 00 DIS;FACTOR AT BLC ON CONDTION
27B 00 00 00 00 DIS;FACTOR AT BLC ON CONDTION
27C 00 00 00 00 DIS;FACTOR AT WDR ON CONDTION
27D 00 00 00 00 DIS;FACTOR AT WDR ON CONDTION
27E F4 F4 F4 F4 DIS;WIGHT WHEN DECREASE
27F 00 00 00 00 DIS; STEP CONTROL '00~88'
“CHANGED BY MODEL”
