SGH-E530 Exploded View and Parts List
3-2
This Document can not be used without Samsung's authorization
3-2. Cellular phone Parts list
Location NO. Description SEC CODE Remark
QFU01 MEC-F/UPPER GH75-06429A
QLC01 LCD GH07-00671A
QSP01 SPEAKER 3001-001752
QMO01 MOTOR DC GH31-00154D
QCA01 UNIT-CAMERA GH59-01965A
QFL01 MEC-F/LOWER GH75-06428A
QGI01 MEC-CUSHION CAMERA FPCB GH75-06498A
QCR05 SCREW-MACHINE 6001-001478
QSC11 RMO-FOLDER SCREW COVER GH73-04205A
QMW02 PMO-MAIN WINDOW GH72-19841A
QFR01 MEC-FRONT COVER GH75-06427A
QRF03 PMO-EAR JACK COVER V4 GH72-21176A
QMI03 MEC-MIC HOLDER GH75-06696A
QKP01 MEC-KEYPAD GH75-06433A
QMP01 PBA MAIN GH92-02041A
QVK01 UNIT-VOLUME KEY GH59-01963A
QME01 UNIT-METAL DOME GH59-01964A
QAN02 INTENNA GH42-00548A
QRE01 MEC-REAR COVER GH75-06430A
QVO01 VOLKEY GH75-06432A
QCK01 CAMERA KEY GH75-07321A
QIF01 PMO-IF COVER GH72-20842A
QBA01 BATTERY GH43-01760A
QSC13 RMO-REAR SCREW COVER GH73-04206A
QRF01 RF SHEET GH74-13533A
