Samsung SGH-E530 - Samsung SGH-E530 Electrical Parts List

SAMSUNG Proprietary-Contents may change without notice
4. SGH-E530 MAIN Electrical Parts List
4-1
This Document can not be used without Samsung's authorization
SEC Code Design LOC Discription
0403-001387 ZD504 DIODE-ZENER
0403-001446 ZD505 DIODE-ZENER
0406-001197 ZD502 DIODE-TVS
0406-001197 ZD503 DIODE-TVS
0504-001138 Q301 TR-DIGITAL
0504-001140 Q201 TR-DIGITAL
0601-001819 LED401 LED
0601-001819 LED402 LED
0601-001819 LED403 LED
0601-001819 LED404 LED
0601-001819 LED405 LED
0601-001819 LED406 LED
0601-001819 LED408 LED
0601-001819 LED409 LED
0601-001819 LED410 LED
0601-001819 LED411 LED
0601-001819 LED413 LED
0601-001819 LED414 LED
0601-001819 LED415 LED
0601-001819 LED416 LED
0601-001819 LED417 LED
0601-001819 LED418 LED
0601-001819 LED419 LED
0601-001819 LED420 LED
0801-002529 U203 IC-CMOS LOGIC
0801-002970 U502 IC-CMOS LOGIC
1001-001306 U302
IC-ANALOG
MULTIPLEX
1009-001020 U201 IC-HALL EFFECT S/W
1108-000003 U202 IC-MCP
1201-002218 U101 IC-POWER AMP
1201-002233 U301 IC-AUDIO AMP
1203-002625 U105 IC-POSI.FIXED REG.
1203-003472 U401
IC-POWER
SUPERVISOR
1203-003616 U304 IC-DC/DC CONVERTER
1203-003629 U501 IC-POSI.FIXED REG.
1203-003667 U205 IC-DC/DC CONVERTER
1203-003730 U306 IC-POSI.FIXED REG.
1204-002138 U400 IC-MELODY
1205-002272 U406 IC-TRANSCEIVER
1205-002433 U102 IC-TRANSCEIVER
1205-002612 U300 IC-CODEC
SEC Code Design LOC Discription
1205-002613 U303 IC-CODEC
1404-001165 TH101 THERMISTOR-NTC
1405-001082 V401 VARISTOR
1405-001082 V402 VARISTOR
1405-001082 V403 VARISTOR
1405-001082 V404 VARISTOR
2007-000138 R102 R-CHIP
2007-000138 R311 R-CHIP
2007-000141 R103 R-CHIP
2007-000148 R106 R-CHIP
2007-000151 R204 R-CHIP
2007-000155 R203 R-CHIP
2007-000162 R105 R-CHIP
2007-000162 R305 R-CHIP
2007-000170 R317 R-CHIP
2007-001291 R444 R-CHIP
2007-001291 R445 R-CHIP
2007-001307 R446 R-CHIP
2007-001307 R447 R-CHIP
2007-001307 R448 R-CHIP
2007-001307 R449 R-CHIP
2007-001307 R450 R-CHIP
2007-001307 R451 R-CHIP
2007-001307 R452 R-CHIP
2007-001307 R453 R-CHIP
2007-001307 R454 R-CHIP
2007-001307 R455 R-CHIP
2007-001307 R456 R-CHIP
2007-001307 R457 R-CHIP
2007-001307 R458 R-CHIP
2007-001307 R459 R-CHIP
2007-001307 R460 R-CHIP
2007-001307 R461 R-CHIP
2007-001307 R462 R-CHIP
2007-001307 R463 R-CHIP
2007-001319 R331 R-CHIP
2007-001323 R107 R-CHIP
2007-001325 R406 R-CHIP
2007-002797 R104 R-CHIP
2007-007528 R443 R-CHIP
2007-008045 R408 R-CHIP
2007-008052 R410 R-CHIP
2007-008054 R348 R-CHIP
