44 | SAMSUNG
INSTALLATION
5
■
DELUXE
1. Review all the following elements in the installation:
◆ Installation site strength
◆ Piping connection tightness to detect any gas leakages
◆ Connection wiring
◆ Heat-resistant insulation of the piping
◆ Drainage
◆ Earthing wire connection
◆ Correct operations (follow the steps below)
2. Press the On/Off button.
3. Press the button.
4. Air flow direction
◆ Press the button and check that the air flow blades work properly.
Result
◆ The temperature and fan settings are adjusted automatically.
◆ If you press the button one or more times until or disappears,
the air conditioner is reset automatically to the previous mode, temperature
and fan settings.
Result
◆ The indicator lights on the indoor unit flash at half-second intervals.
◆ While the indoor unit opens, the indoor unit fan runs to start.
Checking and Testing Operations (cont.)
