52 | SAMSUNG
FEATURES & OPERATION
6
6-2-1. Cooling Mode Operating
When selecting the Cooling Mode Operation, the unit will
operate according to the setting by the remote controller and the
operation is as well as the following. Room temperature can be
set in 1°C steps in the range of 18 to 30°C.
6-2-2. Heating Mode Operation(In case of Heat pump model)
When selecting the Heating Mode Operation, the unit will
operate according to the setting by the remote controller and the
operation is as well as the following. Room temperature can be
set in 1°C steps in the range of 16 to 30°C.
6-2-3. Automatic Operation
When Automatic operation is set by the remote controller, the air conditioner senses the room temperature then automatically selects
the operation mode and setting temperature.
1. In case of Heat pump model.
1. ◆ In case that Room Temp. ≥ 21°C + ∆T, the unit is operated in the Cool Mode.
1. ◆ In case that Room Temp. < 21°C + ∆T, the unit is operated in the Heat Mode.
1. ◆ ∆T means that user is able to change setting temperature within ±2°C.
2. In case of Cooling only model.
1. ◆ In case the Room Temp. ≥ 25°C + ∆T, the unit is operated Compressor.
1. ◆ In case the Room Temp. ≤ 24°C + ∆T, the unit is not operated Compressor.
1. ◆ ∆T means that user is able to change setting temperature within ±2°C.
♦ Ts means Remote Controller setting Temperature
Room Temp.(°C)
Ts+1
Ts
Compressor
ON
OFF
ON
Time
Room Temp.(°C)
Ts+5
Ts+3
Compressor
ON
OFF
ON
Time
Operating Mode Setting Temp. Remarks
Room Temp ≥ 21°C + ∆T Cooling Tsp = 24°C + ∆T
∆T = -2, -1, 0, 1, 2°C
Room Temp < 21°C + ∆T Heating Tsp = 22°C + ∆T
Operating Type Room Temp. Remarks
Cool Operation
Tr ≥ 25°C + ∆T Compressor ON
∆T = -2, -1, 0, 1, 2°C
Tr ≤ 24°C + ∆T Compressor OFF
Details for Operation Property (cont.)
DB98_16444A(1)_1 2/9/04 10:04 AM Page 52
