Samsung SYNCM.400B - Page 14

R102R 260.5 131.5 2001-000665 R-CARBON 33ohm,5%,1/6W,AA,TP,1.8x3.2mm
R103B 256.8 138.5 2001-000025 R-CARBON 75ohm,5%,1/4W,AA,TP,2.4x6.4mm
R103G 254 138.5 2001-000025 R-CARBON 75ohm,5%,1/4W,AA,TP,2.4x6.4mm
R103R 251.3 138.5 2001-000025 R-CARBON 75ohm,5%,1/4W,AA,TP,2.4x6.4mm
R104B 279 230.5 2001-000021 R-CARBON 27ohm,5%,1/4W,AA,TP,2.4x6.4mm
R104G 284 230.5 2001-000021 R-CARBON 27ohm,5%,1/4W,AA,TP,2.4x6.4mm
R104R 289 230.5 2001-000021 R-CARBON 27ohm,5%,1/4W,AA,TP,2.4x6.4mm
R105B 287 215 2001-000084 R-CARBON 100Kohm,5%,1/4W,AA,TP,2.4x6.4m
R105G 312 213 2001-000084 R-CARBON 100Kohm,5%,1/4W,AA,TP,2.4x6.4m
R105R 313.3 233.8 2001-000084 R-CARBON 100Kohm,5%,1/4W,AA,TP,2.4x6.4m
R107B 305 201 2001-000028 R-CARBON(S) 100ohm,5%,1/2W,AA,TP,2.4x6.4mm
R107G 263.5 175.3 2001-000028 R-CARBON(S) 100ohm,5%,1/2W,AA,TP,2.4x6.4mm
R107R 310 183 2001-000028 R-CARBON(S) 100ohm,5%,1/2W,AA,TP,2.4x6.4mm
R108B 317.8 176.5 2001-000029 R-CARBON 100ohm,5%,1/6W,AA,TP,1.8x3.2mm
R108G 323 191.5 2001-000029 R-CARBON 100ohm,5%,1/6W,AA,TP,1.8x3.2mm
R108R 322.3 225.3 2001-000029 R-CARBON 100ohm,5%,1/6W,AA,TP,1.8x3.2mm
R109B 314.5 183 2001-000495 R-CARBON 20Kohm,5%,1/4W,AA,TP,2.4x6.4mm
R109G 323 207.5 2001-000495 R-CARBON 20Kohm,5%,1/4W,AA,TP,2.4x6.4mm
R109R 324.3 227.8 2001-000495 R-CARBON 20Kohm,5%,1/4W,AA,TP,2.4x6.4mm
R110 271.5 219.5 2001-001070 R-CARBON(S) 120ohm,5%,1/2W,AA,TP,2.4x6.4mm
R111 270.3 150 2001-000029 R-CARBON 100ohm,5%,1/6W,AA,TP,1.8x3.2mm
R112 252.3 225.3 2001-000835 R-CARBON 51Kohm,5%,1/4W,AA,TP,2.4x6.4mm
R113 264.5 153 2001-000029 R-CARBON 100ohm,5%,1/6W,AA,TP,1.8x3.2mm
R114 285 167.3 2001-000511 R-CARBON 220ohm,5%,1/2W,AA,TP,3.3x9mm
R115 255.5 163.3 2001-000029 R-CARBON 100ohm,5%,1/6W,AA,TP,1.8x3.2mm
R116 267 153 2001-000029 R-CARBON 100ohm,5%,1/6W,AA,TP,1.8x3.2mm
R117 278 153 2001-000039 R-CARBON 390ohm,5%,1/6W,AA,TP,1.8x3.2mm
R118 272.5 153 2001-000039 R-CARBON 390ohm,5%,1/6W,AA,TP,1.8x3.2mm
R119 294 152 2001-000039 R-CARBON 390ohm,5%,1/6W,AA,TP,1.8x3.2mm
R120 254.8 194 2001-000056 REF-CF,4.7K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R121 252 176.8 2001-000090 R-CARBON 180Kohm,5%,1/6W,AA,TP,1.8x3.2m
R122 247 183.5 2001-000077 R-CARBON 47Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R201 69 33 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R202 66.5 33 2001-000077 R-CARBON 47Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R205 59 33 2001-000496 R-CARBON 20Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R206 56.5 33 2001-000496 R-CARBON 20Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R208 27.5 17 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R210 33 17 2001-000035 REF-CF,220,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R212 62.5 86 2001-000562 R-CARBON 27Kohm,5%,1/6W,AA,TP,1.8x3.2mm 15
R213 37.5 67.3 2001-000029 R-CARBON 100ohm,5%,1/6W,AA,TP,1.8x3.2mm
R214 32.5 67.3 2001-000029 R-CARBON 100ohm,5%,1/6W,AA,TP,1.8x3.2mm
R215 26.5 36 2001-000108 R-CARBON 18Kohm,5%,1/6W,AA,TP,1.8x3.2mm 15
2001-000069 R-CARBON 12Kohm,5%,1/6W,AA,TP,1.8x3.2mm 14”
R216 80 77.5 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R217 29 36 2001-000101 R-CARBON 11Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R218 31.5 35.9 2001-000367 R-CARBON 15Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R219 42.5 68 2001-000043 REF-CF,1K,5%,1/6W 150V,-1300 TO +350PPM,R-AXI
10 PCB Diagrams and Electrical Parts List
CKA42*7L/5227L 10-11
Loc. No. Coordinates (X,Y) New Code No. Description Specification Remarks
