Samsung SYNCM.400B - Page 15

R220 48 39.5 2001-000097 R-CARBON 1Mohm,5%,1/6W,AA,TP,1.8x3.2mm
R221 51.5 33 2001-000868 R-CARBON 56ohm,5%,1/6W,AA,TP,1.8x3.2mm
R222 54 33 2001-000868 R-CARBON 56ohm,5%,1/6W,AA,TP,1.8x3.2mm
R223 65 68 2001-000868 R-CARBON 56ohm,5%,1/6W,AA,TP,1.8x3.2mm
R224 67.5 68 2001-000868 R-CARBON 56ohm,5%,1/6W,AA,TP,1.8x3.2mm
R225 25 27 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R226 51.3 96.8 2001-000040 R-CARBON 470ohm,5%,1/6W,AA,TP,1.8x3.2mm
R227 44.3 101.5 2001-000077 R-CARBON 47Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R228 46.8 101.5 2001-000077 R-CARBON 47Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R229 32.5 11 2001-000042 R-CARBON 1Kohm,5%,1/4W,AA,TP,2.4x6.4mm
R230 60 109.5 2001-000868 R-CARBON 56ohm,5%,1/6W,AA,TP,1.8x3.2mm
R231 54.3 17 2001-000053 R-CARBON 3.3Kohm,5%,1/6W,AA,TP,1.8x3.2m
R232 56.8 17 2001-000053 R-CARBON 3.3Kohm,5%,1/6W,AA,TP,1.8x3.2m
R233 65.8 27 2001-000029 R-CARBON 100ohm,5%,1/6W,AA,TP,1.8x3.2mm
R234 54 109.5 2001-000868 R-CARBON 56ohm,5%,1/6W,AA,TP,1.8x3.2mm
R235 61.8 17 2001-000868 R-CARBON 56ohm,5%,1/6W,AA,TP,1.8x3.2mm
R236 56.5 109.5 2001-000868 R-CARBON 56ohm,5%,1/6W,AA,TP,1.8x3.2mm
R237 48.3 25 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R238 59.3 17 2001-000868 R-CARBON 56ohm,5%,1/6W,AA,TP,1.8x3.2mm
R239 77.5 81 2001-001099 REF-CF,2.7K,5%,1/2W(S 300V,-200 TO +200PPM/C,R-AX
R240 62.5 109.5 2001-000056 REF-CF,4.7K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R241 25 119.5 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R242 25 109.8 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R243 25 107.3 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R244 25 94.8 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R245 37 117 2001-000106 R-CARBON 1.5Kohm,5%,1/6W,AA,TP,1.8x3.2m
R246 37 114.5 2001-000106 R-CARBON 1.5Kohm,5%,1/6W,AA,TP,1.8x3.2m
R247 37 104.8 2001-000106 R-CARBON 1.5Kohm,5%,1/6W,AA,TP,1.8x3.2m
R248 37 102.3 2001-000106 R-CARBON 1.5Kohm,5%,1/6W,AA,TP,1.8x3.2m
R249 22.5 116 2001-000889 REF-CF,6.8K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R250 22.5 109.3 2001-000889 REF-CF,6.8K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R251 22.5 104.5 2001-000889 REF-CF,6.8K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R252 13 67 2001-000889 REF-CF,6.8K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R253 15 119 2001-000367 R-CARBON 15Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R254 13.5 136.5 2001-000367 R-CARBON 15Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R256 222.5 107 2001-000868 R-CARBON 56ohm,5%,1/6W,AA,TP,1.8x3.2mm
R257 222.5 104.5 2001-000553 R-CARBON 270ohm,5%,1/6W,AA,TP,1.8x3.2mm
R258 222.5 102 2001-000553 R-CARBON 270ohm,5%,1/6W,AA,TP,1.8x3.2mm
R259 224 98.5 2001-000868 R-CARBON 56ohm,5%,1/6W,AA,TP,1.8x3.2mm
R260 247.3 109.5 2001-000868 R-CARBON 56ohm,5%,1/6W,AA,TP,1.8x3.2mm
R262 40 67.3 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R264 21.5 20.5 2001-000652 R-CARBON 330ohm,5%,1/6W,AA,TP,1.8x3.2mm
R266 40.8 115.5 2001-000053 R-CARBON 3.3Kohm,5%,1/6W,AA,TP,1.8x3.2m
R267 30.5 27 2001-000072 R-CARBON 22Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R268 17.3 53 2001-000367 R-CARBON 15Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R269 18 74 2001-000889 REF-CF,6.8K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R270 45 68 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
10 PCB Diagrams and Electrical Parts List
10-12 CKA42*7L/5227L
Loc. No. Coordinates (X,Y) New Code No. Description Specification Remarks
