R271 227.5 109.5 2001-000056 REF-CF,4.7K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R301 132 109.7 2001-000056 REF-CF,4.7K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R302 94 89.5 2001-000056 REF-CF,4.7K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R305 93.5 68 2001-000059 REF-CF,5.6K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R306 93.5 70.5 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R307 133.5 17.5 2008-000003 R-FUSIBLE 0.22ohm, 5%, 1/2W, AT, TP, 3.5x9.4mm
R308 149.5 11.8 2008-000003 R-FUSIBLE 0.22ohm, 5%, 1/2W, AT, TP, 3.5x9.4mm
R309 125.5 35.5 2001-000245 REF-CF,1.5,5%,1/2W 350V,-350 TO +350PPM/C,R-AX
R310 136.5 75.3 2003-000650 R-METAL OXIDE(S) 330ohm,5%,2W,AA,TP,4x12mm
R311 121.5 55 2004-001022 REF-MF,5.6K,1%,1/4W 250V,-100 TO +100PPM/C,R-AX
R312 121.5 80 2003-000412 R-METAL OXIDE(S) 0.9ohm,5%,2W,AA,TP,4x12mm
R313 101.5 59.5 2001-000069 R-CARBON 12Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R314 101.5 45 2001-000104 R-CARBON 1.2Kohm,5%,1/6W,AA,TP,1.8x3.2m
R315 101.5 50.8 2001-000064 R-CARBON 7.5Kohm,5%,1/6W,AA,TP,1.8x3.2m
R316 88 21 2001-000075 R-CARBON 39Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R317 85.5 39.5 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R318 104.5 28.5 2001-000043 REF-CF,1K,5%,1/6W 150V,-1300 TO +350PPM,R-AXI
R319 88 30.5 2001-000064 R-CARBON 7.5Kohm,5%,1/6W,AA,TP,1.8x3.2m
R320 100.5 17 2003-000807 R-METAL OXIDE(S) 82ohm,5%,2W,AA,TP,4x12mm
R321 85.5 28 2001-000083 R-CARBON 82Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R322 111.3 84.3 2001-000066 R-CARBON(S) 10Kohm,5%,1/2W,AA,TP,2.4x6.4mm
R401 185.5 132.8 2001-000072 R-CARBON 22Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R403 28.5 144.5 2001-000043 REF-CF,1K,5%,1/6W 150V,-1300 TO +350PPM,R-AXI
R404 28.5 147 2001-000043 REF-CF,1K,5%,1/6W 150V,-1300 TO +350PPM,R-AXI
R405 72 143 2001-000097 R-CARBON 1Mohm,5%,1/6W,AA,TP,1.8x3.2mm
R406 47.8 128 2004-001136 R-METAL 6.8Kohm,1%,1/4W,AA,TP,2.4x6.4m
R407 81 137.5 2001-000106 R-CARBON 1.5Kohm,5%,1/6W,AA,TP,1.8x3.2m
R408 55.8 134.3 2001-000048 REF-CF,2.2K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R409 44.5 163 2001-000043 REF-CF,1K,5%,1/6W 150V,-1300 TO +350PPM,R-AXI
R410 78.5 178.8 2003-000587 R-METAL OXIDE(S) 22ohm,5%,1W,AA,TP,3.3x9mm
R412 69.5 221.3 2001-000020 REF-CF,22,5%,1/2W(S 300V,-200 TO +200PPM/C,R-AX
R414 111.3 220.5 2001-000016 R-CARBON(S) 1ohm,5%,1/2W,AA,TP,2.4x6.4mm
R415 135.5 218 2001-000525 R-CARBON 22ohm,5%,1/4W,AA,TP,2.4x6.4mm
R416 75.5 215 2003-000009 R-METAL OXIDE(S) 220ohm,5%,1W,AA,TP,3.3x9mm
R417 68 178.8 2001-001107 REF-CF,220,5%,1/2W(S 300V,-200 TO +200PPM/C,R-AX
R418 58.5 183.5 2001-000404 R-CARBON 180ohm,5%,1/6W,AA,TP,1.8x3.2mm
R419 63.5 198.5 2001-000043 REF-CF,1K,5%,1/6W 150V,-1300 TO +350PPM,R-AXI
R420 29.8 192 2001-000048 REF-CF,2.2K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R421 27 192 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R422 19.5 217.1 2001-000097 R-CARBON 1Mohm,5%,1/6W,AA,TP,1.8x3.2mm
R423 9.5 217 2001-000097 R-CARBON 1Mohm,5%,1/6W,AA,TP,1.8x3.2mm
R424 51 179.3 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R425 53.5 179.3 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R427 23 216.9 2001-000076 REF-CF,47K,5%,1/4W 250V,-600 TO -150PPM/C,R-AX
R428 12.5 217 2001-000076 REF-CF,47K,5%,1/4W 250V,-600 TO -150PPM/C,R-AX
R430 163 114 2001-000721 R-CARBON 4.3Kohm,5%,1/4W,AA,TP,2.4x6.4m
R431 168 151.5 2001-000089 REF-CF,150K,5%,1/6W 150V,-1300 TO + 350PPM/C,R-
!
10 PCB Diagrams and Electrical Parts List
CKA42*7L/5227L 10-13
Loc. No. Coordinates (X,Y) New Code No. Description Specification Remarks
