Samsung SYNCM.400B - Page 17

R432 80.5 119.3 2001-000090 R-CARBON 180Kohm,5%,1/6W,AA,TP,1.8x3.2m 15”
2001-000086 R-CARBON 100Kohm,5%,1/6W,AA,TP,1.8x3.2m 14”
R434 166.5 102.8 2001-000538 R-CARBON 24Kohm,5%,1/6W,AA,TP,1.8x3.2mm 15”
2001-000562 R-CARBON 27Kohm,5%,1/6W,AA,TP,1.8x3.2m
R435 163 143.5 2001-000053 R-CARBON 3.3Kohm,5%,1/6W,AA,TP,1.8x3.2m
R436 165.5 143.5 2001-000836 R-CARBON 51Kohm,5%,1/6W,AA,TP,1.8x3.2mm 15”
R437 55.5 161 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R438 74 115 2001-000088 R-CARBON 120Kohm,5%,1/6W,AA,TP,1.8x3.2m
R439 18.8 88 2001-000868 R-CARBON 56ohm,5%,1/6W,AA,TP,1.8x3.2mm
R440 18.8 90.5 2001-000868 R-CARBON 56ohm,5%,1/6W,AA,TP,1.8x3.2mm
R441 47.5 115 2001-000367 R-CARBON 15Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R442 78 143 2001-000531 R-CARBON 240Kohm,5%,1/8W,AA,TP,1.8x3.2m
R443 75 154.8 2001-000547 R-CARBON 270Kohm,5%,1/6W,AA,TP,1.8x3.2m
R444 216.5 189.5 2001-000067 REF-CF,10K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R445 98.3 126.5 2001-000106 R-CARBON 1.5Kohm,5%,1/6W,AA,TP,1.8x3.2m
R447 75.1 193.8 2003-000276 R-METAL OXIDE 33ohm,5%,1W,AA,TP,4.3x12mm
R448 131.5 197 2001-000246 R-CARBON 1.5ohm,5%,1/4W,AA,TP,2.4x6.4mm
R502 92.5 165.5 2001-000069 R-CARBON 12Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R503 81.5 160 2001-000079 R-CARBON 56Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R504 198.5 231.5 2001-000562 R-CARBON 27Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R505 210.5 226.5 2001-000104 R-CARBON 1.2Kohm,5%,1/6W,AA,TP,1.8x3.2m
R506 95 153.3 2004-000216 R-METAL 10Kohm,1%,1/4W,AA,TP,2.4x6.4mm
R507 81 140 2001-000075 R-CARBON 39Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R508 95 162.5 2004-000284 R-METAL 12Kohm,1%,1/4W,AA,TP,2.4x6.4mm
R509 82.5 177.5 2004-004095 R-METAL 2.36Kohm,1%,1/4W,AA,TP,2.4x6.4
R510 184.5 230 2001-000836 R-CARBON 51Kohm,5%,1/6W,AA,TP,1.8x3.2mm
R511 219 209 2001-000057 REF-CF,5.1K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R512 180.3 144 2001-000547 R-CARBON 270Kohm,5%,1/6W,AA,TP,1.8x3.2m
R513 227.3 167.3 2008-000106 REF-FUSIBLE,0.56,5%,1/2W -350 TO +350PPM/C,R-AXIAL
R515 158 114 2001-000889 REF-CF,6.8K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
R516 224 189.5 2001-000688 R-CARBON 390Kohm,5%,1/6W,AA,TP,1.8x3.2m
R518 212.5 211.5 2001-000090 R-CARBON 180Kohm,5%,1/6W,AA,TP,1.8x3.2m
R520 180.3 141.5 2001-000115 R-CARBON 82Kohm,5%,1/4W,AA,TP,2.4x6.4mm
2001-000078 R-CARBON 56Kohm,5%,1/4W,AA,TP,2.4x6.4mm 14” ORION
R521 207.5 156.5 2001-000107 R-CARBON(S) 150Kohm,5%,1/2W,AA,TP,2.4x6.4m
R522 206.5 159 2001-000096 R-CARBON(S) 1Mohm,5%,1/2W,AA,TP,2.4x6.4mm
R523 216 218 2001-000688 R-CARBON 390Kohm,5%,1/6W,AA,TP,1.8x3.2m
R524 213.3 215.5 2001-000106 R-CARBON 1.5Kohm,5%,1/6W,AA,TP,1.8x3.2m
R525 212.8 135.3 2001-000100 R-CARBON 2.2Mohm,5%,1/6W,AA,TP,1.8x3.2m
R527 105 182.3 2001-001099 REF-CF,2.7K,5%,1/2W(S 300V,-200 TO +200PPM/C,R-AX
R528 124 167.8 2003-000007 REF-MO,82,5%,3W(S 350V,-350 TO +350PPM/C,R-AX
R529 108 182.3 2001-000110 REF-CF,10,5%,1/4W 250V,-350 TO +350PPM/C,R-AX
R530 102.5 129 2005-000401 R-WIRE WOUND 0.47ohm,5%,2W,AA,TP,4x12mm
R531 122.5 147.5 2003-000386 REF-MO,910,5%,2W 350V,-200 TO +200PPM/C,R-AX
R532 221.5 189.5 2001-000091 R-CARBON 220Kohm,5%,1/6W,AA,TP,1.8x3.2m
R534 74 157.3 2001-000097 R-CARBON 1Mohm,5%,1/6W,AA,TP,1.8x3.2mm
R536 190 130 2001-000048 REF-CF,2.2K,5%,1/6W 150V,-1300 TO +350PPM/C,R-A
!
!
!
!
10 PCB Diagrams and Electrical Parts List
10-14 CKA42*7L/5227L
Loc. No. Coordinates (X,Y) New Code No. Description Specification Remarks
